Tryton drill motor stand for hammer drill TDW1050/TDW1050K model YTDW05SS, compatible with Ø39 mm

This motor stand is designed for Tryton hammer drill models TDW1050 and TDW1050K (model YTDW05SS). It provides a rigid, fixed mounting interface for the drill motor, enabling stationing or guided drilling operations where improved alignment and control are required. The stand is compatible with drills that use a Ø39 mm mounting interface and is intended for workshop use to increase drilling accuracy, repeatability and operator safety during bench or vertical drilling tasks.

Advantages

The stand offers a firm and repeatable mounting solution that reduces motor movement and improves hole alignment compared with handheld operation. By securing the drill in a fixed position it simplifies guided drilling, allows consistent depth control and enhances operator safety during high-torque or vertical drilling. Its compatibility with a Ø39 mm interface ensures quick installation for supported Tryton models while keeping the work area organized and stable.

Suitable for

• Guided bench drilling of metal, wood and plastics
• Vertical drilling where repeatable hole placement is required
• Workshop jigs and prototyping requiring fixed motor alignment
• Tasks that require improved operator safety and reduced fatigue

Key specifications

• Compatibility: designed for Tryton TDW1050 and TDW1050K drill motors with Ø39 mm mounting
• Mount type: fixed motor stand for guided drilling applications
• Intended use: bench and vertical drilling in workshop environments
• Primary benefits: improved accuracy, repeatability and stability

How to use

Mount the drill motor into the stand’s Ø39 mm interface and secure according to the motor’s mounting requirements. Position the stand on a stable bench or base and clamp or bolt it in place if necessary. Align the workpiece and adjust the vertical travel or depth stop as required for the task. Operate the drill motor while the stand guides the bit along the intended axis to maintain consistent hole placement and depth.

Usage recommendations

Use the stand on a stable, level workbench and verify the motor is correctly seated and fastened before applying power. Select appropriate drill bits and speeds for the material, and use clamping to secure the workpiece. Regularly inspect mounting points and fasteners for wear or loosening to maintain safety and accuracy.
