Holder for brush set for Tryton hammer drill TMM710K (YTMM01SC) — brush holder compatible with models 79, 80, 81

Holder for brush set for Tryton hammer drill TMM710K (YTMM01SC) is a replacement brush holder assembly designed to restore and secure carbon brushes in compatible hammer drill models 79, 80 and 81. This component provides the necessary mechanical mounting and electrical connection between the brushes and the commutator, enabling reliable current transfer, reducing sparking and helping maintain stable motor performance during operation.

Advantages

The brush holder assembly is manufactured to match the original interface and mounting points of the Tryton TMM710K series, offering a direct-fit replacement that simplifies repair and maintenance. It restores proper brush alignment and pressure, which improves electrical contact and contributes to reduced wear on the commutator. The unit supports continued safe operation of the hammer drill and helps extend the service life of the tool by enabling timely brush replacement.

Suitable for

• Repair and maintenance of Tryton hammer drill models referenced as 79, 80 and 81
• Workshops and service centres performing electric motor brush replacements
• Professional tradespeople and DIY users maintaining TMM710K-compatible tools

Key specifications

• Function: brush holder assembly for carbon brushes providing mechanical mounting and electrical connection
• Compatibility: designed for Tryton TMM710K-compatible models (79, 80, 81)
• Material: durable insulating housing with conductive contacts for brush connection
• Mounting: direct-fit replacement matching original mounting points and connector layout
• Role in device: restores brush pressure and alignment to maintain commutator contact and reduce sparking

How to use

Before starting, disconnect the tool from its power source. Remove the drill housing covers to access the motor and existing brush holders, following the manufacturer service instructions. Unscrew and remove the defective brush holder, detach the worn carbon brushes if present, and fit the replacement holder in the same position. Insert carbon brushes into the holder, ensure correct orientation and spring tension, and reattach electrical connectors. Reassemble the housing and test the tool under no-load conditions to confirm correct installation and smooth motor operation.

Usage recommendations

Use replacement brush holders together with appropriately sized carbon brushes recommended for Tryton TMM710K-compatible models. Inspect brushes and commutator for wear when replacing the holder; replace worn brushes and clean or service the commutator as needed to ensure reliable electrical contact and minimize sparking.
