Wireless access point Ubiquiti E7-Campus — IEEE 802.11be, 2.4/5/6 GHz, 11.5 Gbit/s, PoE, 2x RJ‑45

Mobile operating systems supported:

iOS, Android

Power

Power over Ethernet (PoE):

Yes

DC voltage range:

42.5 - 57

Power consumption (max):

44 W

Power over Ethernet (PoE) type supported:

PoE++ (4PPoE)

Features

Maximum data transfer rate:

11500 Mbit/s

Networking standards:

IEEE 802.11be

Rate limiting:

Yes

Ethernet LAN data rates:

1000, 10000

2.4 GHz:

Yes

5 GHz:

Yes

MIMO:

Yes

Dynamic Frequency Selection (DFS):

Yes

Fast roaming:

Yes

Band steering:

Yes

MIMO type:

Multi User MIMO

Maximum data transfer rate (2.4 GHz):

688 Mbit/s

Maximum data transfer rate (5 GHz):

8600 Mbit/s

6 GHz:

Yes

Maximum data transfer rate (6 GHz):

11500 Mbit/s

Maximum Tx power (2.4 GHz):

23 dBmW

Maximum Tx power (5 GHz):

30 dBmW

Spatial streams:

10

Coverage area:

465 m²

Maximum Tx power (6 GHz):

30 dBmW

Wireless meshing:

Yes

Security

Security algorithms:

PPSK, TLS

Remote Authentication Dial-In User Service (RADIUS):

Yes

Design

LED indicators:

Y

Product colour:

White

Housing material:

Polycarbonate (PC)

International Protection (IP) code: Device protection rating against dust and water according to the international IP standard.

IPX6, IP67

Placement:

Ceiling, Pole, Wall

Antenna

Antenna type:

Internal

Antenna gain level (max):

12 dBi

Antennas quantity:

1

Antenna direction type:

Directional

Certificates

Certification:

FCC, IC US/CA

Compliance certificates:

National Defense Authorization Act (NDAA)

Operational conditions

Operating relative humidity (H-H):

5 - 95

Operating temperature (T-T):

-30 - 60

Weight & dimensions

Weight:

2.2 kg

Height:

250 mm

Width:

250 mm

Depth:

45.5 mm

Ports & interfaces

USB 2.0 ports quantity:

0

Ethernet LAN (RJ-45) ports:

2
