Mini PC Viewsonic VPC35-W53-G1 Intel Core i5 8GB RAM 256GB SSD Intel UHD Graphics 630 Windows 11 Pro

Short description

The Viewsonic VPC35-W53-G1 is a compact mini PC featuring an Intel® Core™ i5-1240P processor with a frequency of 2 GHz. It comes with 8 GB of DDR4-SDRAM and a 256 GB SSD for fast storage. The integrated Intel® UHD Graphics 630 provides reliable graphics performance. Running on Windows 11 Pro (64-bit), this slot-in PC is perfect for both work and entertainment. Weighing only 1.95 kg, it is easy to transport and fits seamlessly into any workspace.

Warranty: 2 Years

SKU: 10776918

Information regarding the items availability for purchase will be posted on this site

Item cost information will be published on this site

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ViewSonic VPC35-W53-G1 is a slot-in mini PC designed to power interactive displays and presentation panels. Equipped with an Intel® Core™ i5-1240P processor, 8 GB DDR4 memory and a 256 GB SSD, it delivers responsive performance for classroom lessons, meetings and collaborative sessions. Integrated Intel UHD Graphics and Windows 11 Pro ensure compatibility with common educational and business applications while compact, lightweight construction allows easy installation into compatible ViewBoard® or presentation displays.

Advantages

This mini PC provides a balance of processing power and portability: the Intel 12th Gen Core i5 CPU and SSD storage speed up application launch and multitasking. Built-in Intel WiFi and Bluetooth 5.1 offer fast wireless connectivity, while multiple ports (4K-capable HDMI, DisplayPort 1.4, USB 3.0 and Gigabit LAN) enable diverse peripherals and network connections. System stability is enhanced by FinchGuard watchdog software and an optional Secure Boot in BIOS increases startup security. A thermal control circuit and low-noise fan keep operation cool and quiet.

Suitable for (tasks / use cases)

Interactive classroom displays and digital whiteboards
Corporate presentation panels and meeting room installations
Remote and hybrid teaching or conferencing
Small office PC for productivity applications

Key specifications

Processor: Intel Core i5-1240P, base frequency 2 GHz, boost up to 3.6 GHz
Memory: 8 GB DDR4
Storage: 256 GB SSD
Graphics: Integrated Intel UHD Graphics
Connectivity: Dual-band WiFi (Intel), Bluetooth 5.1, Gigabit Ethernet (RJ45)
Video outputs: HDMI (4K capable), DisplayPort 1.4
USB: USB 3.0 ports
Operating system: Windows 11 Pro (64-bit)
Weight and form factor: compact slot-in design, approx. 1.95 kg
Acoustics and cooling: thermal control circuit with low-noise fan (under 35 dB)

How to use

Insert the VPC35-W53-G1 into the compatible slot of your ViewBoard or presentation display following the manufacturer’s mechanical guide. Connect power and required peripherals such as display cables (HDMI or DP), ethernet or WiFi, and USB devices. Configure Windows 11 Pro and install required educational or meeting software. Use BIOS options to enable Secure Boot if startup protection is required, and verify FinchGuard watchdog settings for automatic recovery behavior.

Usage recommendations

For stable classroom or meeting operation, keep the ventilation clear and place the display in a location with adequate airflow to maintain the device below typical acoustic levels. Regularly update Windows and myViewBoard software to ensure compatibility and security when using interactive lessons and presentations.

Specifications

Processor model:: i5-1240P
Processor frequency:: 2 GHz
Processor boost frequency:: 3.6 GHz
Internal memory:: 8 GB
Internal memory type:: DDR4-SDRAM
SSD capacity:: 256 GB
Discrete graphics card model:: Not available
Operating system installed:: Windows 11 Pro
Weight:: 1.95 kg
Product colour:: Black

All features

Processor

Processor model:: i5-1240P
Processor frequency:: 2 GHz
Processor boost frequency:: 3.6 GHz
Processor cores:: 6
Processor cache:: 12 MB
Configurable TDP-down:: 25 W
Configurable TDP-down frequency:: 1.3 GHz
Processor manufacturer:: Intel
CPU configuration (max):: 1

Processor special features

Enhanced Intel SpeedStep Technology:: Yes
Execute Disable Bit:: Yes
Idle States:: Yes
Intel Trusted Execution Technology:: No
Intel VT-x with Extended Page Tables (EPT):: Yes
Embedded options available:: No
Intel 64:: Yes
Intel Stable Image Platform Program (SIPP):: No
Intel Virtualization Technology for Directed I/O (VT-d):: Yes
Intel Clear Video Technology:: Yes
Intel Software Guard Extensions (Intel SGX):: Yes
Intel Virtualization Technology (VT-x):: Yes

Memory

Internal memory:: 8 GB
Internal memory type:: DDR4-SDRAM
Maximum internal memory:: 8 GB

Storage

Total storage capacity:: 256 GB
SSD capacity:: 256 GB
SSD interface:: PCI Express, SATA III
Number of SSDs installed:: 1
Storage media:: SSD
SSD form factor:: M.2
Total SSDs capacity:: 256 GB

Graphics

Discrete graphics card model:: Not available
Discrete graphics card:: No
On-board graphics card:: Yes
On-board GPU manufacturer:: Intel

Network

Wi-Fi:: Yes
Bluetooth:: Yes
Ethernet LAN:: Yes
Bluetooth version:: 5.2
Ethernet LAN data rates:: 10, 100, 1000
Top Wi-Fi standard:: Wi-Fi 6 (802.11ax)

Ports & interfaces

Ethernet LAN (RJ-45) ports:: 1
USB 2.0 ports quantity:: 2
Headphone outputs:: 1
Microphone in:: Yes
HDMI ports quantity:: 1
HDMI version:: 2.0
DisplayPorts quantity:: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:: 1

Software

Operating system installed:: Windows 11 Pro
Operating system architecture:: 64-bit
Bundled software:: myViewBoard for Window /Adobe reader /Winflash /Watch Dog

Technical details

Compliance certificates:: CE, REACH, RoHS, WEEE

Design

Product colour:: Black
Chassis type:: Slot-in PC
Colour name:: Black

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Operating temperature (T-T):: -5 - 45

Weight & dimensions

Weight:: 1.95 kg
Package weight:: 2100 g
Height:: 263.4 mm
Width:: 246.2 mm
Depth:: 32.2 mm
Package depth:: 90 mm
Package height:: 310 mm
Package width:: 350 mm

Other features

Display included:: No

Certificates

Certification:: cTUVus, FCC, FCC ID, IC ID, CE, RED, CB, BSMI, NCC, RoHS, ErP, REACH, WEEE

Performance

Optical drive type:: No
Motherboard chipset:: Intel H410
Product type:: Mini PC

Power

Power supply input voltage:: 110 - 240
Power supply input frequency:: 50 - 60

Logistics data

Harmonized System (HS) code:: 84715000

Sustainability

Sustainability certificates:: ErP
