RTK GNSS Module XGRIDS Lixel L2 Pro Dual Frequency — high-precision positioning module

Surveyor-grade RTK kit for XGRIDS Lixel L2 Pro is a high-precision positioning accessory designed to improve the accuracy of the XGRIDS Lixel L2 Pro scanner. The kit extends transmission range and supports multiple satellite systems to deliver reliable position data with horizontal accuracy of 0.8 cm + 1 ppm and vertical accuracy of 1.5 cm + 1 ppm, making it suitable for demanding surveying and scanning environments.

Advantages

The RTK kit increases positioning reliability in complex conditions by combining extended transmission range with multi-constellation GNSS support. It enables centimeter-level horizontal and vertical accuracy for the XGRIDS Lixel L2 Pro and includes necessary mounting components for integration.

Key specifications

• Manufacturer: XGRIDS
• Product code (MPN): CZ02020003
• Supported channels: GPS L1/L2/L5; GLONASS L1/L2; BDS B1/B2/B3; Galileo E1/E5a/E5b/E6b
• Horizontal accuracy: 0.8 cm + 1 ppm
• Vertical accuracy: 1.5 cm + 1 ppm

How to use

Mount the measuring RTK module onto the XGRIDS Lixel L2 Pro using the supplied mounting and mounting screws. Configure the scanner to use external RTK positioning according to the scanner's setup procedure and ensure the module receives corrections from a compatible RTK base or network. Verify satellite reception and check reported horizontal and vertical accuracy values before beginning surveying tasks.

Recommendations

Use the RTK kit in open-sky conditions when possible to maximise GNSS reception. Regularly check firmware compatibility between the RTK module and the XGRIDS Lixel L2 Pro, and perform a quick verification of positioning accuracy on-site before critical measurements.
