AMUE SPA Whirlpool AMOG-1633 230x230 cm, 6 seats, corner spa bathtub

AMUE SPA Whirlpool AMOG-1633 is a corner spa bathtub sized 230x230x96 cm with seating for five. Designed for hydrotherapy and communal use, the unit includes a stainless steel frame, a 3 kW inline heater, an ozone generator for water sanitation, BALBOA full control electronics and a set of multi-size water and air jets integrated flush with the acrylic surface. Power supply required: 380V / 50Hz three-phase.

Advantages

The bathtub uses 100% USA acrylic with increased thickness for durability and wear resistance. Jets are mounted flush in the acrylic so users do not lie directly on the nozzles. All jet fittings are stainless steel to reduce corrosion and scaling. The stainless steel support frame provides a strong base suitable for larger filled tubs. Fiber-optic lighting and a seven-color underwater lamp deliver stable, bright illumination. BALBOA controls manage pumps, ozone, lighting and heating with three preset heating modes (sleep, economy, standard) for temperature management.

Suitable for

• Residential hydrotherapy and relaxation
• Small commercial settings such as guest houses or wellness rooms
• Muscle relief and improved circulation
• Social bathing for up to five users

Key specifications

• Dimensions: 230 x 230 x 96 cm
• Seats: 5
• Color: White
• Power: 380V / 50Hz (three-phase)
• Acrylic: USA acrylic (100% acrylic)
• Frame: Stainless steel
• Water jets total: 61 (37 of 2.5" incl. 16 rotating; 16 of 3.5" incl. 7 rotating; 5 of 5" incl. 4 rotating; 3 of 7")
• Water pump: 3 HP / 2.25 kW (1 unit)
• Circulation pump: 0.35 HP / 0.25 kW (1 unit)
• Air jets: 12
• Air pump: 0.7 kW (1 unit)
• Aeration valves: 4 x Easy-Flow Air Venturi
• LED strip with 25 lights; 1 spa lamp (7 colors)
• Ozone generator
• Heater: 3 kW
• Drain valve: 1
• Intake valves: 4
• Water filters: 2
• Controller: BALBOA full control

How to use

Install the AMOG-1633 on a solid, level base with adequate load-bearing capacity and connect to a compatible three-phase 380V / 50Hz electrical supply by a qualified electrician. Fill the tub with water, set the BALBOA control to the desired functions (pumps, lighting, ozone, heater) and select one of the three heating presets to reach and maintain the required temperature. Use built-in controls to operate jets and lighting while monitoring water quality and levels.

Usage recommendations

Operate the ozone generator periodically to maintain water hygiene and replace the bath water approximately every six months. Regularly inspect and clean filters and stainless steel jets to prevent buildup. Ensure the heater is active during SPA sessions to keep water temperature stable; follow local electrical safety standards for installation and maintenance.
