KVM Switch ATEN CS19216

Name: KVM Switch ATEN CS19216 Rack CS19216
Brand: ATEN
SKU: 4133157
Price: 1640.99 EUR
Availability: InStock

Shop for gifts early

Save time and money with our discounts!

KVM Switch ATEN CS19216 Rack Mounting USB DisplayPort 4K Ultra HD

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The ATEN CS19216 is a 1U rack-mountable KVM switch that supports USB keyboard and mouse connections. It features DisplayPort video output with a maximum resolution of 4096 x 2160 pixels at 4K Ultra HD. The device is housed in a durable metal casing and consumes 26.66 W of power. Ideal for managing multiple computers in a server rack environment.

Available for order: 7 pcs.

Warranty: 2 Years

SKU: 4133157

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

10.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

10.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

15.07.2026 {{selectedOffer.courierDeliveryString}}

From 5.23 € (Weight: 5.34 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

15.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

pay in 3 equal parts

today

0 €

afterward

3 mth. х 547 €

overpayment

0 €

All payment Methods Hide details

All payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment, Leasing for legal entities

36 months installment: from 45.58 euros per month

Leasing for legal entities: from 57.11 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ATEN CS19216 16-Port USB 3.0 4K DisplayPort KVM Switch is a 1U rack-mountable unit that provides centralized access and control of up to 16 DisplayPort computers using a single USB keyboard, USB mouse and monitor console. It features a dual-interface console with both DisplayPort and HDMI video output options and supports resolutions up to 4K DCI (4096 x 2160 @ 60Hz). The metal-housed device includes an integrated USB 3.1 Gen 1 hub for high-speed peripheral and data transfer and consumes 26.66 W of power.

Advantages

The CS19216 supports cascading to two levels to extend control up to 256 computers from a single console and can stack up to eight units to enable multi-display comparisons across up to eight monitors. Built-in ATEN technologies — Video DynaSync™ and EDID Expert™ — optimize display resolution, speed up port switching and prevent boot-up display issues. Multiple port selection methods are provided, including front-panel pushbuttons, keyboard hotkeys, RS-232 commands and an on-screen display (OSD) with a redesigned user interface. Two-level password authorization enhances access security for managed systems.

Suitable for

Server rooms and data center racks where centralized control is required
Enterprise and government environments managing multiple DisplayPort workstations
Environments requiring high-quality 4K visuals such as finance, medical imaging and telecom
Industrial automation and production control applications

Key specifications

Model: ATEN CS19216
Form factor: 1U rack-mountable, metal housing
Ports controlled: 16 DisplayPort computers (expandable via cascade to 256)
Video output: DisplayPort / HDMI (dual-interface console)
Maximum resolution: 4096 x 2160 @ 60Hz (4K DCI)
USB hub: Built-in USB 3.1 Gen 1 (up to 5 Gbps)
Power consumption: 26.66 W
Weight: 3.54 kg
Security: Two-level password authorization

How to use

Mount the CS19216 in a 19" rack and connect the console monitor to either the DisplayPort or HDMI port on the front console. Connect the USB keyboard and mouse to the console USB ports and link each target computer to the KVM using DisplayPort and USB connections. Use the front-panel pushbuttons, keyboard hotkeys, RS-232 commands or the OSD to switch between computers. For larger installations, cascade additional CS19216 units (up to two levels) to expand control to as many as 256 computers or stack up to eight units for multi-monitor comparison.

Usage recommendations

For best display performance, use high-quality DisplayPort cables rated for 4K@60Hz and enable EDID Expert™ features; plan rack mounting and cable routing to ensure proper ventilation and stable power supply. Regularly update firmware and maintain strong password policies for access control.

Specifications

Mouse port type:: USB
Keyboard port type:: USB
Video port type:: DisplayPort
Weight:: 3.54 kg
Number of computers controlled:: 16
Product colour:: Black

All features

Ports & interfaces

Serial ports quantity:: 1
USB connector type:: USB Type-A, USB Type-B
Headphone outputs:: 18
DC-in jack:: Yes
Keyboard port type:: USB
Mouse port type:: USB
Video port type:: DisplayPort
Number of computers controlled:: 16
Audio connections:: Yes
HDCP:: Yes
DisplayPorts quantity:: 16
DisplayPort version:: 1.2
USB hub:: Yes
Console ports:: 3.5mm headphone, DisplayPort, HDMI, USB A
Console USB ports quantity:: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity:: 2

Performance

Maximum resolution:: 4096 x 2160
Hot-Plug support:: Yes
Scan interval:: 255
Firmware upgradeable:: Yes
HD type:: 4K Ultra HD

Design

Rack mounting:: Yes
Hot keys:: Yes
LED indicators:: Y
Product colour:: Black
Rack capacity:: 1U
Housing material:: Metal
Push button:: Yes
Cascadable:: Yes

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.: 26.66 W
Power source:: AC
External power adapter:: Yes

Operational conditions

Operating relative humidity (H-H):: 0 - 80
Storage temperature (T-T):: -20 - 60
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 0 - 80

Weight & dimensions

Weight:: 3.54 kg
Height:: 44 mm
Width:: 432.4 mm
Depth:: 214.3 mm

Display

On Screen Display (OSD):: Yes
Built-in display:: No

System requirements

Windows operating systems supported:: Y
Mac operating systems supported:: Y
Linux operating systems supported:: Y

Hide Show all

Instructions

mmo_87238132_1622633963_1357_51832.pdf

aten-CS19216-4133157.pdf

Description

Instructions

mmo_87238132_1622633963_1357_51832.pdf

aten-CS19216-4133157.pdf

Machine translation. Load original

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Customer reviews

Show all reviews

Customer questions

FAQ

How much does the KVM Switch ATEN CS19216 cost, and is it available for purchase?

The price is 1,640.99 € (valid at the time of publication and already includes all taxes). The item is available for order — 7 pcs. are in stock, and you can place your purchase right now with delivery across Latvia and Europe or choose pickup at the Riga collection point. We offer favorable purchase terms, including the option to split the payment into convenient monthly installments. Availability and price are updated in real time, so we recommend placing your order in advance.

If I order this product today, when will I receive my order?

If you place your order today, delivery will be as fast and convenient as possible. You will be able to pick up your order on 10.07.2026 at the Riga pickup point or choose delivery across Latvia and Europe. We carefully inspect every purchase and pack it securely for safe transportation.

What payment options are available?

AiO.lv offers several payment methods: Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment, Leasing for legal entities. All transactions are 100% secure and encrypted.

Can KVM Switch ATEN CS19216 be purchased with a lease?

Yes, the purchase is available both on credit and with an interest-free installment plan. We work with leading banks and leasing companies in Latvia, allowing you to make your purchase on convenient terms — with a minimal down payment and a repayment period from 3 to 36 months. You can apply for credit or installments for the KVM Switch ATEN CS19216 online, and the application process is as simple as possible:

Select the product on the website and add it to your cart;
When placing your order, choose the payment method “Installments”;
Fill in the required details for the lending partner;
Receive a decision within a few minutes.

For more information about available payment options, interest-free installment terms, and credit conditions in Latvia, please visit the Payment page.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All ATEN products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized ATEN service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: mouse port type, keyboard port type, video port type, weight, number of computers controlled, product colour, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.

Where can I download the instructions for KVM Switch ATEN CS19216?

You can download the instructions in PDF format from the “Instructions” section on the product description page. The file contains complete information about installation, setup, and usage.
