Unmanaged Switch Edimax GS-1005E

Name: Unmanaged Switch Edimax GS-1005E GS-1005E
Brand: EDIMAX
SKU: 3664087
Price: 17.49 EUR
Availability: InStock

Shop for gifts early

Save time and money with our discounts!

Unmanaged Switch Edimax GS-1005E Photo 3

Unmanaged Switch Edimax GS-1005E Photo 4

Unmanaged Switch Edimax GS-1005E Photo 5

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The Edimax GS-1005E is an unmanaged Gigabit Ethernet switch with 5 RJ-45 ports, supporting speeds of 10/100/1000 Mbps. It features a MAC address table with 2000 entries and a switching capacity of 10 Gbit/s. Compliant with IEEE networking standards, it operates on a 5V DC input and is wall mountable, making it a versatile choice for home or office networking needs.

Available at price 17.49 €: 100 pcs.

Total available for order: 539 pcs.

Warranty: 2 Years

SKU: 3664087

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

06.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.37 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

06.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Edimax GS-1005E is an unmanaged 5-port Gigabit Ethernet desktop switch designed to upgrade or expand wired networks in homes, small offices and enterprise environments. It supports 10/100/1000 Mbps speeds on each RJ-45 port, a MAC address table of 2000 entries and a 10 Gbit/s switching capacity. The compact metal housing is fanless and can be placed on a desk or mounted on a wall.

Advantages

The GS-1005E provides full-duplex Gigabit connectivity with up to 2000 Mbps throughput per port and supports 9K jumbo frames to improve large file transfers. It offers plug-and-play ease with Auto-Negotiation, Auto-MDI/MDI-X and Flow Control, and uses a store-and-forward architecture to filter fragment and CRC error packets. The switch also complies with IEEE 802.3az Energy Efficient Ethernet and includes inactive link and cable-length detection to reduce power consumption.

Suitable for

Home wired networks and media sharing
Small office network expansion for desktops and printers
Workstation and server uplinks requiring Gigabit speeds
Environments needing a quiet, fanless metal switch with optional wall mounting

Key specifications

Model: Edimax GS-1005E
Switch type: Unmanaged
Ports: 5 × RJ-45 Gigabit Ethernet (10/100/1000 Mbps)
Switching capacity: 10 Gbit/s
MAC address table: 2000 entries
Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3az
Jumbo frames: 9K supported
Power: DC 5V input
Colour: Black
Weight: 0.229 kg

How to use

Connect the GS-1005E to a power source using the supplied 5V DC adapter, then plug Ethernet cables from your router, modem or other network devices into the RJ-45 ports. The device is plug-and-play and requires no configuration. For optimal performance, use Cat5e or Cat6 cables to support Gigabit speeds and enable full-duplex operation where supported by connected devices.

Usage recommendations

Place the switch on a flat surface or mount it on a wall using the mounting slots. Keep the unit in a well-ventilated area despite the fanless design, and use high-quality Ethernet cables to ensure reliable Gigabit connections. The energy-saving features will reduce power draw when links are inactive.

Specifications

Switch type:: Unmanaged
Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 5
Weight:: 0.229 kg
10G support:: No
Networking standards:: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Product colour:: Black

All features

Management features

Switch type:: Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 5

Power over Ethernet (PoE)

Power over Ethernet (PoE):: No

Data transmission

MAC address table:: 2000 entries
Transmission method:: Store and forward
Switching capacity:: 10 Gbit/s
Jumbo frames support:: Yes
Forwarding rate:: 7.44 Mpps
Packet buffer memory:: 0.128 MB
Packet forwarding rate (1 Gbps):: 1448000 pps
Packet forwarding rate (10 Mbps):: 14880 pps
Packet forwarding rate (100 Mbps):: 148800 pps
Jumbo frames:: 9000

Certificates

Certification:: CE, FCC

Power

Input current:: 1
DC input voltage:: 5
Power consumption (max):: 2.4 W
Power supply included:: Yes

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Storage temperature (T-T):: -40 - 70
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 5 - 90

Logistics data

Harmonized System (HS) code:: 85176990

Weight & dimensions

Weight:: 0.229 kg
Height:: 26 mm
Width:: 121 mm
Depth:: 75 mm

Network

Networking standards:: IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support:: No

Design

Rack mounting:: No
LED indicators:: Link, Activity, Power
Wall mountable:: Yes
Product colour:: Black
Stackable:: No
Housing material:: Metal

Performance

Fanless:: Yes
