Circuit breaker (automatic switch) electro base ETIMAT 6 1P 6kA C-13A

Circuit breaker (automatic switch) electro base ETIMAT 6 1P 6kA C-13A is a single-pole miniature circuit breaker designed to provide overcurrent protection in residential and light commercial electrical installations. With a rated current of 13 A and a breaking capacity of 6 kA, this device interrupts fault currents quickly to protect wiring and connected equipment. The type C tripping characteristic provides dependable response to overloads while accommodating moderate inrush currents from motors and transformers.

Advantages

The electro base ETIMAT 6 1P 6kA C-13A offers compact dimensions for DIN-rail mounting and straightforward installation in distribution boards. Its 6 kA breaking capacity balances safety and cost-effectiveness for typical household and small-business circuits. The C characteristic ensures selective tripping behavior for common inductive loads, reducing nuisance trips while preserving protection. The device is produced to standard electrical safety requirements and is suitable for coordinated use with other protective components.

Suitable for

• Protection of lighting and socket circuits in homes and apartments
• Small commercial premises such as offices and retail spaces
• Feeder circuits for HVAC units, small motors, and pumps with moderate startup currents
• Retrofit or new installations in standard DIN-rail distribution enclosures

Key specifications

• Pole count: single-pole (1P)
• Rated current: 13 A
• Tripping characteristic: Type C (moderate inrush tolerance)
• Breaking capacity: 6 kA
• Intended mounting: DIN-rail compatible
• Application: AC circuits for residential and light commercial use

How to use

Install the circuit breaker on a standard DIN rail inside the distribution board. Ensure supply and load conductors are de-energized before connection. Connect the line conductor to the incoming terminal and the load conductor to the outgoing terminal, tighten terminals to the recommended torque, and verify polarity. After installation, restore power and test the circuit by switching the device on and off; perform functional testing and coordination checks with upstream or downstream protective devices as required by local electrical codes.

Usage recommendations

Use this circuit breaker for circuits with steady currents at or below 13 A and for loads with moderate inrush. For circuits with high fault-current potential or motor starting currents exceeding the device's rating, select a breaker with appropriate breaking capacity or coordination. Periodically inspect connections and perform testing according to local regulations to ensure continued reliable operation.
