Remote Switch extra digital RTU5024 — GSM/4G remote I/O controller with 4 relay outputs

The extra digital RTU5024 is a GSM remote switch and I/O controller with four relay outputs designed for remote control and access automation via the mobile network. It allows switching of gates, doors, lighting and other electrical devices without the need for internet or data transmission. The device recognizes authorized caller numbers and operates relays by rejecting the incoming call from an authorized number, enabling free remote control by phone. The controller supports quad-band GSM and can be configured by SMS commands or via a smartphone app. It is compact, made of aluminum, and intended for installation in residential, agricultural, industrial and business environments.

Advantages

The RTU5024 works over 2G quad-band networks and provides up to four dry-contact relays with programmable open/close times; it accepts up to 200 authorized phone numbers managed by SMS. Setup and user management are done by SMS or the dedicated smartphone app, no continuous maintenance is required after configuration. The unit supports secure caller ID recognition so unknown callers are ignored, operates with wide supply voltage (9–24 V DC) and includes an SMA antenna interface for reliable GSM reception. The kit includes the controller, antenna, two connection adapters and an instruction sheet, and is covered by a 24-month warranty.

Suitable for

• Remote open/close of swing or sliding gates and garage doors
• Access control for houses, cottages and residential buildings
• Remote switching of pumps, street lights, motors and inverters
• Control of industrial equipment, billboards and LED signage
• Remote management of household appliances (fans, air conditioners, microwaves)

Key specifications

• GSM frequency: 2G, quad-band 850/900/1800/1900 MHz
• Power supply: 9–24 V DC, 2 A
• Outputs: NC/NO dry contacts, 3 A / 240 V AC
• Power consumption: at 12 V input max 50 mA, average 25 mA
• SIM card: 3 V mini SIM
• Antenna interface: 50 Ω SMA
• Operating temperature: -20 °C to +60 °C, up to 90% RH
• Material: aluminum; Dimensions: 102 × 76 × 27 mm; Weight: 108 g
• Optional battery: 3.7 V / 900 mAh (sold separately)
• Included: GSM controller, GSM antenna, 2 connection adapters, instruction
• Warranty: 24 months

How to use

Install the RTU5024 in a location with adequate GSM signal and connect the power supply (9–24 V DC). Insert a 3 V mini SIM card and attach the supplied antenna to the SMA connector. Program authorized phone numbers and relay parameters via SMS commands or use the RTU5024 smartphone app for configuration. Control devices by calling from an authorized number; the unit will identify the caller and toggle the corresponding relay without charging the call. Configure relay open/close durations and add or remove users by SMS as required.

Usage recommendations

For reliable operation, mount the controller in a weather-protected enclosure, ensure a stable DC power source, and place the antenna where GSM reception is strongest. If used in applications requiring backup power, fit the recommended 3.7 V / 900 mAh battery or an appropriate external supply. Confirm local mobile network 2G availability before deployment.
