Managed Gigabit Ethernet Switch Hikvision DS-3E1505P-EI/M

Name: Managed Gigabit Ethernet Switch Hikvision DS-3E1505P-EI/M
Brand: Hikvision
SKU: 11636769
Price: 47.99 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Managed Gigabit Ethernet Switch Hikvision DS-3E1505P-EI/M PoE

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The Hikvision DS-3E1505P-EI/M is a managed Gigabit Ethernet switch featuring 5 ports with Power over Ethernet (PoE) support. It is designed for efficient network management and power delivery to connected devices, making it ideal for IP cameras and wireless access points. This switch ensures reliable performance and easy integration into existing networks.

Available at price 47.99 €: 12 pcs.

Total available for order: 24 pcs.

Warranty: 2 Years

SKU: 11636769

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

30.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

30.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

03.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.71 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

03.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Hikvision Managed Gigabit Ethernet Switch DS-3E1505P-EI/M PoE is a compact managed switch with five Gigabit Ethernet ports and integrated Power over Ethernet (PoE) capability. Designed for small surveillance and network access deployments, the switch supplies power and data to IP cameras and wireless access points while offering management functions for topology visibility, device monitoring and alarm reporting. Its grey metal housing and 45 W total PoE budget enable reliable edge connectivity and straightforward integration into existing networks.

Advantages

This managed PoE switch supports full Gigabit speeds on all RJ‑45 ports and provides centralized power delivery to connected devices, reducing the need for separate power adapters. Management features include VLAN support, spanning tree protocols and PoE watchdog for automated camera reboot, which simplifies maintenance and improves uptime. Built‑in surge protection and long‑range PoE transmission extend deployment flexibility and help protect equipment in surveillance and access network scenarios.

Suitable for

Small IP camera systems and CCTV edge aggregations
Indoor wireless access point connections that require PoE
Office network segments and branch network edge devices
Locations requiring remote device monitoring and reboot capability

Key specifications

Switch type: Managed Gigabit Ethernet switch
Ports: 4 × Gigabit PoE RJ‑45 ports, 1 × Gigabit RJ‑45 port
Data rates: 10/100/1000 Mbps on all ports
Total PoE power budget: 45 W
PoE standards: IEEE 802.1af and IEEE 802.3at compatible
MAC address table capacity: 2000 entries
Switching capacity: 10 Gbit/s
Long‑range PoE: up to 300 m transmission support
Protection: 6 kV surge protection
Physical: lightweight compact grey enclosure, weight approx. 0.26 kg

How to use

Install the switch on a stable surface or mount according to the device documentation and connect the uplink Gigabit port to your network core or router. Connect PoE‑powered devices such as IP cameras or access points to the PoE RJ‑45 ports; the switch will supply power automatically according to the connected device’s standard (802.1af/802.3at). Access the management interface via the provided Hikvision software platform or web/CLI management tools to configure VLANs, STP/RSTP, PoE watchdog and other network policies. Monitor device status and alarms through the management platform to ensure continuous operation.

Usage recommendations

For optimal performance, allocate the PoE budget according to each device’s power consumption and avoid overloading the total 45 W budget. Use VLANs to separate surveillance traffic from general office traffic, enable STP/RSTP to prevent loops in redundant topologies, and enable the PoE watchdog for remote recovery of non‑responsive cameras. Place the switch in a ventilated indoor environment and protect it from moisture and extreme temperatures.

Specifications

Switch type:: Managed
Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 5
Weight:: 0.26 kg
10G support:: No
Networking standards:: IEEE 802.1af, IEEE 802.3at
Product colour:: Grey

All features

Power

Power source:: DC/PoE
Input current:: 0.92
Surge protection voltage:: 6 kV
Surge protection:: Yes
DC input voltage:: 54
Power consumption (max):: 50 W

Power over Ethernet (PoE)

Power over Ethernet (PoE):: Yes
Power over Ethernet (PoE) ports quantity:: 4
Total Power over Ethernet (PoE) budget:: 45 W
Power over Ethernet (PoE) power per port:: 30 W

Sustainability

Sustainability compliance:: Yes

Management features

Switch type:: Managed

Ports & interfaces

Gigabit Ethernet (copper) ports quantity:: 5
Installed SFP+ modules quantity:: 0
Installed SFP modules quantity:: 0
Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 5
Power connector:: DC-in jack

Design

Rack mounting:: No
LED indicators:: Y
Product colour:: Grey
Stackable:: No
Housing material:: Metal

Operational conditions

Operating relative humidity (H-H):: 5 - 95
Storage temperature (T-T):: -40 - 85
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 5 - 95

Network

Networking standards:: IEEE 802.1af, IEEE 802.3at
Link aggregation:: Yes
Number of VLANs:: 32
VLAN support:: Yes
10G support:: No
Virtual LAN features:: VLAN Identifier ( VLAN ID)

Optical fiber

Transmission distance (max):: 0.3 km

Data transmission

MAC address table:: 2000 entries
Switching capacity:: 10 Gbit/s
Forwarding rate:: 7.44 Mpps

Weight & dimensions

Weight:: 0.26 kg
Height:: 27.6 mm
Width:: 121.1 mm
Depth:: 83.1 mm

Packaging data

Package weight:: 750 g

Security

Loop protection:: Yes
DHCP features:: DHCP client

Certificates

Compliance certificates:: CB, Low Voltage Directive (LVD), REACH, RoHS
