header-product Circuit breaker HiSmart NV821426 miniature 1P 16A DIN rail
3.99 €

Circuit breaker HiSmart NV821426 miniature 1P 16A DIN rail

Circuit breaker HiSmart NV821426 1P 16A Photo 1
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Circuit breaker HiSmart NV821426 miniature 1P 16A DIN rail

{{email}}
You keep track of price changes

Circuit breaker HiSmart NV821426 miniature 1P 16A DIN rail

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

Miniature circuit breaker HiSmart NV821426 is a single-pole (1P) protective device rated for 16 A. Designed for mounting on DIN rail, it provides overcurrent protection for residential or light commercial electrical circuits. Suitable for protecting wiring and connected equipment, it enables quick manual reset after trips and simple integration into distribution boards.
Available for order: 5 pcs.
Warranty: 2 Years
SKU: 10840431
Manufacturer: HiSmart
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
02.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
07.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 €
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
07.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
payment
Payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

Miniature circuit breaker HiSmart NV821426 is a single-pole (1P) protective device rated at 16 A and Class C tripping characteristic. Designed for DIN-rail (35 mm) mounting, it provides overload and short-circuit protection for residential and light-commercial circuits and allows manual resetting after a trip. The housing is flame-retardant, resistant to high temperature and impact, and features a contact position indicator (red = closed, green = open).

Advantages

The HiSmart NV821426 combines short-circuit and overload protection with a 6 kA breaking capacity and a clear contact position indicator. It supports top and bottom connections for cables and pin-type busbars, accepts conductors up to 25 mm² (or 18-3 AWG for busbar), and is rated to IEC/EN 60898-1 standards. Mechanical durability and electrical life ratings (20,000 mechanical operations and 8,000 electrical operations) make it suitable for repeated use in distribution boards.

Suitable for

  • Protection of lighting and socket circuits in homes
  • Overcurrent protection in small commercial installations
  • Integration into DIN-rail distribution boards

Key specifications

  • Number of poles: 1P
  • Rated current: 16 A
  • Tripping class: C
  • Rated voltage: AC 230/400 V
  • Insulation voltage (Ui): 500 V
  • Rated frequency: 50/60 Hz
  • Rated breaking capacity (Icu): 6000 A
  • Rated impulse withstand voltage (Uimp): 6000 V
  • Mechanical life: 20,000 operations
  • Electrical life: 8,000 operations
  • Protection degree: IP20
  • Terminal connection: cable / pin-type busbar, top and bottom
  • Wire / busbar cross-section: up to 25 mm² / 18-3 AWG
  • Dimensions (H×W×D): 85.5 × 78.8 × 18 mm
  • Standards: IEC 60898-1 / EN 60898-1

How to use

Mount the HiSmart NV821426 on a standard 35 mm DIN rail using the fast clip device. Connect supply and load conductors to the top and bottom terminals respectively, observing correct polarity and using appropriate conductor cross-sections up to 25 mm² (or 18-3 AWG for busbar). After installation, switch the breaker to the ON position; if it trips due to overload or short circuit, identify and clear the fault, then manually reset the breaker to restore power. Operate within the ambient temperature range of -5 °C to +40 °C (daily average < 35 °C).

Usage recommendations

Use the device only in accordance with IEC/EN 60898-1 requirements. Verify conductor sizes and tighten terminals to manufacturer-recommended torque values. Do not exceed the rated current or breaking capacity, and ensure regular inspection in environments with dust or corrosive conditions.
