header-product Circuit breaker HiSmart NV821501 2-pole 20 A Class C miniature DIN-rail
7.99 €

Circuit breaker HiSmart NV821501 2-pole 20 A Class C miniature DIN-rail

HiSmart NV821501 2P 20A Class C circuit breaker Photo 1
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Circuit breaker HiSmart NV821501 2-pole 20 A Class C miniature DIN-rail

{{email}}
You keep track of price changes

Circuit breaker HiSmart NV821501 2-pole 20 A Class C miniature DIN-rail

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

Miniature circuit breaker HiSmart NV821501 is a 2-pole, 20 A device with Class C tripping curve designed for DIN-rail mounting. It provides overcurrent and short-circuit protection for residential and commercial circuits, suitable for distribution boards and branch circuit protection. Compact design saves panel space and enables reliable automatic disconnection to protect wiring and equipment.
Available for order: 5 pcs.
Warranty: 2 Years
SKU: 10840439
Manufacturer: HiSmart
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
02.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
07.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 €
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
07.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
payment
Payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

Miniature circuit breaker HiSmart NV821501 is a 2-pole, 20 A Class C device for DIN-rail mounting. It provides overload and short-circuit protection with a 6 kA breaking capacity and is intended for use in distribution boards and branch circuits to protect wiring and connected equipment. The breaker features a compact design, contact position indication and can be connected from top or bottom to cables or pin-type busbars.

Advantages

The HiSmart NV821501 offers reliable overcurrent protection and a Class C tripping characteristic suitable for general-purpose circuits. It includes an anti-mistake contact terminal block, flame-retardant housing with high temperature and impact resistance, and clear contact position indication (red = closed, green = open). DIN-rail fast clip installation and support for cable and pin-type busbar connections simplify panel assembly.

Suitable for

  • Residential distribution boards
  • Commercial branch circuit protection
  • Protection of lighting and socket circuits
  • DIN-rail electrical panels where space is limited

Key specifications

  • Number of poles: 2
  • Rated current: 20 A
  • Tripping class: C
  • Rated voltage (Ue): AC 400 V
  • Insulation voltage (Ui): 500 V
  • Rated frequency: 50/60 Hz
  • Rated breaking capacity (Icu): 6000 A
  • Rated impulse withstand voltage (Uimp): 6000 V
  • Mechanical life: 20,000 cycles
  • Electrical life: 8,000 cycles
  • Safety class: IP20
  • Terminal connection type: cable / pin-type busbar
  • Wire/busbar cross-section: up to 25 mm² / 18-3 AWG
  • Connection direction: top and bottom
  • Mounting: DIN-rail EN 60715 (35 mm) with fast clip
  • Operating temperature: -5°C to +40°C (daily average <35°C)
  • Storage temperature: -25°C to +70°C
  • Dimensions: 85.5 x 78.8 x 36 mm
  • Standards: IEC 60898-1 / EN 60898-1

How to use

Install the HiSmart NV821501 onto a 35 mm DIN rail (EN 60715) using the built-in fast clip device. Make electrical connections to the terminal block from top or bottom using appropriate cable or pin-type busbar with cross-sections up to 25 mm²; ensure correct tightening torque per installation practice. Use the breaker to protect branch circuits by wiring it into the live conductors; observe the tripping class C characteristics when selecting for loads with moderate inrush currents. Verify contact position indication (red = closed, green = open) after wiring and before energising the circuit.

Usage recommendations

Select the HiSmart NV821501 according to the circuit’s nominal current and expected inrush; do not exceed the rated current or breaking capacity. Ensure installation and maintenance are performed by qualified personnel and follow local electrical codes and the standards IEC 60898-1 / EN 60898-1.
