header-product Surge Protection Device HiSmart NV821730 2‑pole 1000 VDC
41.99 €

Surge Protection Device HiSmart NV821730 2‑pole 1000 VDC

Surge Protection Device HiSmart NV821730 2P 1000VDC Photo 1
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Surge Protection Device HiSmart NV821730 2‑pole 1000 VDC

{{email}}
You keep track of price changes

Surge Protection Device HiSmart NV821730 2‑pole 1000 VDC

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

HiSmart NV821730 is a DC surge protection device designed for 2‑pole PV and DC installations with a nominal voltage rating of 1000 VDC. It provides transient overvoltage protection to safeguard inverters, string combiners and DC cabling from surges. Intended for commercial and residential solar systems, it is installed at the DC side to reduce equipment damage and downtime.
Available for order: 5 pcs.
Warranty: 2 Years
SKU: 10841783
Manufacturer: HiSmart
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
02.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
07.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 €
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
07.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
payment
Payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

HiSmart NV821730 is a 2-pole surge protection device rated for 1000 V DC designed to protect DC power systems, photovoltaic arrays and wind-generation DC equipment from transient overvoltages caused by switching events, induction lightning and direct lightning influence. The device conforms to IEC 61643-1 and CE standards and is intended for installation on the DC side of inverters, string combiners and other DC circuits to reduce equipment damage and downtime.

Advantages

The NV821730 offers Class B protection with a high maximum discharge current up to 100 kA and a nominal discharge current of 60 kA, a fast response time under 25 ns and a voltage protection level of ≤ 5 kV. It supports continuous operating voltages up to 1000 V DC, is rated for a wide operating temperature range (–40 °C to +85 °C) and is designed for DIN-rail (35 mm) mounting with 4–6 mm² conductor connections. Compliance with IEC 61643-1 and CE provides verified safety and performance criteria.

Suitable for

  • Photovoltaic (PV) string combiner boxes and DC arrays
  • Inverter DC input protection
  • Wind power DC systems and other industrial DC installations
  • Commercial and residential solar PV systems

Key specifications

  • Poles: 2
  • Class: B
  • Maximum continuous operating voltage (Uc): 1000 V DC
  • Nominal discharge current (In): 60 kA
  • Maximum discharge current (Imax): 100 kA
  • Voltage protection level (Up): ≤ 5 kV
  • Response time: < 25 ns
  • Frequency: 50/60 Hz
  • Operating temperature: -40 °C to +85 °C
  • Relative humidity (at 25 °C): < 95%
  • Installation: 35 mm DIN rail
  • Wire cross-section: 4–6 mm²
  • Dimensions: 54 x 90 x 67 mm
  • Standards: IEC 61643-1, CE
  • Warranty: 24 months

How to use

Mount the HiSmart NV821730 on a 35 mm DIN rail in the DC section of the PV or DC installation, close to the equipment to be protected (for example, string combiner or inverter DC input). Connect the two poles to the corresponding positive and negative DC conductors using appropriate 4–6 mm² wiring and ensure secure terminations. Verify system voltage does not exceed the 1000 V DC rating before energizing. Observe manufacturer and local electrical codes when performing installation and commissioning.

Usage recommendations

Install surge protection at the DC source and distribution points; periodically inspect connections and the device after severe surge events. Replace the protector if it shows signs of damage or after rated discharge events beyond nominal specifications.
