Managed Switch Aruba Instant On 1930 48G PoE 370W 4SFP 1U

Managed Switch Aruba Instant On 1930 48G PoE Photo 1
Managed Switch Aruba Instant On 1930 48G PoE Photo 2
Managed Switch Aruba Instant On 1930 48G PoE Photo 3
Managed Switch Aruba Instant On 1930 48G PoE Photo 1
Managed Switch Aruba Instant On 1930 48G PoE Photo 2
Managed Switch Aruba Instant On 1930 48G PoE Photo 3
Managed Switch Aruba Instant On 1930 48G PoE Photo 1
Managed Switch Aruba Instant On 1930 48G PoE Photo 2
Managed Switch Aruba Instant On 1930 48G PoE Photo 3
Managed Switch Aruba Instant On 1930 48G PoE Photo 1
Managed Switch Aruba Instant On 1930 48G PoE Photo 2
Managed Switch Aruba Instant On 1930 48G PoE Photo 3
Managed Switch Aruba Instant On 1930 48G PoE 370W 4SFP 1U
Out of stock.
View similar!
Out of stock.
View similar!

Short description

The Aruba Instant On 1930 48G PoE switch offers 48 Gigabit Ethernet ports, 370W PoE power, and advanced L2+ management features, suitable for small to medium networks.
Warranty: 2 Years
SKU: 10777348
delivery
Information regarding the items availability for purchase will be posted on this site
price
Item cost information will be published on this site
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Aruba Instant On 1930 48G PoE 370W 4SFP 1U is a managed Gigabit Ethernet switch designed for small and growing businesses that need reliable performance and flexible Power-over-Ethernet (PoE) delivery. This 48-port model provides Gigabit RJ-45 connectivity across all ports, up to 370W total PoE budget for powering IP phones, wireless access points and cameras, and four SFP/SFP+ slots for fiber or uplink connections. The switch supports layer 2+ features, multiple management options including cloud-based Instant On management and a local web GUI, and a compact 1U rackable form factor in white.

Advantages

The switch combines a full set of managed switching functions—VLANs, link aggregation, Spanning Tree variants and IEEE 802.1X—with Class 4 PoE (PoE+) capability and 10G-capable SFP+ uplinks on the 48-port model. Energy Efficient Ethernet and built-in security mechanisms such as access control, DoS protection and management privilege levels reduce operational risks and power consumption. Simple out-of-the-box deployment and compatibility with the Instant On mobile app and web portal make provisioning and remote monitoring straightforward.

Suitable for

  • Small offices and branch locations requiring centralized wired connectivity and PoE for endpoints
  • Retail stores and hospitality venues deploying IP cameras, VoIP phones and access points
  • Workspaces needing fiber uplinks or longer distance connections via SFP/SFP+ ports
  • Environments where cloud or local management and basic L2+ features are required

Key specifications

  • Ports: 48 Gigabit RJ-45 ports
  • PoE: Up to 370 W total PoE budget (Class 4 / PoE+ capability)
  • SFP/SFP+ slots: 4 slots supporting 1G/10G transceivers for uplinks
  • Switch type: Managed, Layer 2+ feature set (VLAN, link aggregation, Spanning Tree, 802.1X)
  • Supported standards: IEEE 802.1Q, 802.3af, 802.3at, 802.3ab, 802.3, 802.1x, 802.1w, 802.1s, 802.1p, 802.1ab, 802.1D, 802.3z, 802.3x, 802.3u
  • 10G support: Yes (via SFP+ slots)
  • Form factor and colour: 1U rack-mountable chassis, white
  • Weight: 4.59 kg

How to use

Install the switch in a standard 19-inch rack or place it on a stable surface. Connect network devices to the Gigabit RJ-45 ports and insert SFP/SFP+ transceivers for fiber uplinks where required. Power the switch and, if using PoE devices, ensure the total PoE consumption does not exceed the 370 W budget by planning port power allocation. For management, choose Instant On cloud management using the mobile app or web portal for remote monitoring and configuration, or access the local web GUI for on-site configuration and firmware updates.

Usage recommendations

Plan PoE device distribution to avoid exceeding the 370 W budget; allocate high-power devices across different ports or use scheduling where supported. Use SFP+ modules for uplinks when connecting to core switches or servers requiring 10G throughput, and enable appropriate VLANs and 802.1X policies to isolate traffic and improve network security.

Specifications

Basic switching RJ-45 Ethernet ports type:
Gigabit Ethernet (10/100/1000)
Switch type:
Managed
Weight:
4.59 kg
Basic switching RJ-45 Ethernet ports quantity:
48
10G support:
Yes
Networking standards:
IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ab, IEEE 802.3, IEEE 802.1x, IEEE 802.1w, IEEE 802.1s, IEEE 802.1p, IEEE 802.1ab, IEEE 802.3at, IEEE 802.1D, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u
Product colour:
White
All features

Ports & interfaces

Basic switching RJ-45 Ethernet ports type:
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:
48
SFP+ module slots quantity:
4

Management features

Switch layer:
L2+
Quality of Service (QoS) support:
Yes
Web-based management:
Yes
Switch type:
Managed
Cloud-managed:
Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE):
Yes
Total Power over Ethernet (PoE) budget:
370 W

Power

Power source:
AC
AC input frequency:
50 - 60
AC input voltage:
100 - 240
Power consumption (max):
520 W
Power supply included:
Yes

Performance

Processor frequency:
800 MHz
Internal memory:
512 MB
Processor model:
ARM Cortex-A9
Flash memory:
256 MB
Memory type:
SDRAM / Flash
Built-in processor:
Yes

Design

Rack mounting:
Yes
Form factor:
1U
Product colour:
White
Stackable:
No

Operational conditions

Operating altitude:
0 - 3048
Operating relative humidity (H-H):
15 - 95
Storage temperature (T-T):
-40 - 70
Operating temperature (T-T):
0 - 40
Storage relative humidity (H-H):
15 - 95

Weight & dimensions

Weight:
4.59 kg
Height:
43.9 mm
Width:
442.5 mm
Depth:
322.6 mm

Data transmission

MAC address table:
16000 entries
Switching capacity:
176 Gbit/s
Jumbo frames support:
Yes
Packet buffer memory:
1.5 MB
Latency (10-100 Mbps):
4.5 µs
Latency (1 Gbps):
2.2 µs
Latency (10 Gbps):
1.2 µs
Throughput:
130.95 Mpps

Network

Full duplex:
Yes
Networking standards:
IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ab, IEEE 802.3, IEEE 802.1x, IEEE 802.1w, IEEE 802.1s, IEEE 802.1p, IEEE 802.1ab, IEEE 802.3at, IEEE 802.1D, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u
Flow control support:
Yes
Port mirroring:
Yes
Link aggregation:
Yes
Rate limiting:
Yes
Auto MDI/MDI-X:
Yes
Spanning tree protocol:
Yes
VLAN support:
Yes
10G support:
Yes
Auto-sensing:
Yes

Security

Access Control List (ACL):
Yes
SSH/SSL support:
Yes
IGMP snooping:
Yes
DHCP features:
DHCP client
