INTELLINET 561754 8-Port Gigabit Ethernet Switch

Name: 8-Port Gigabit Ethernet Switch INTELLINET 561754
Brand: INTELLINET
SKU: 11229520
Price: 46.49 EUR
Availability: InStock

Shop for gifts early

Save time and money with our discounts!

8-Port Gigabit Ethernet Switch INTELLINET 561754, Desktop, Plastic, IEEE 802.3az, 8× RJ-45 10/100/1000, 16 Gbit/s

INTELLINET 561754 8-Port Gigabit Ethernet Switch Photo 1

INTELLINET 561754 8-Port Gigabit Ethernet Switch Photo 2

INTELLINET 561754 8-Port Gigabit Ethernet Switch Photo 3

INTELLINET 561754 8-Port Gigabit Ethernet Switch Photo 4

INTELLINET 561754 8-Port Gigabit Ethernet Switch Photo 5

INTELLINET 561754 8-Port Gigabit Ethernet Switch Photo 6

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

Unmanaged 8-port Gigabit Ethernet switch by INTELLINET (model 561754) in a compact desktop plastic housing. Provides eight RJ-45 10/100/1000 ports with full-duplex switching, 16 Gbit/s switching capacity and a 4,000-entry MAC address table. Supports IEEE 802.3 standards including 802.3az energy-efficient Ethernet. Powered via 5 V DC; suitable for small offices, home networks and edge connectivity.

Available for order: 4 pcs.

Warranty: 2 Years

SKU: 11229520

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

06.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.15 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

06.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The INTELLINET 8-Port Gigabit Ethernet Switch (desktop, plastic) is an unmanaged network switch designed to expand wired connectivity for small offices, home networks and edge deployments. It delivers eight RJ-45 10/100/1000 Mbps ports with full-duplex switching and a 16 Gbit/s switching capacity. The switch supports IEEE 802.3 standards including energy-efficient Ethernet (IEEE 802.3az) and maintains a MAC address table sized for up to 4,000 entries. Powered by a 5 V DC adapter, the compact plastic housing is suitable for desktop placement and simple plug-and-play installation.

Advantages

This unmanaged Gigabit switch provides straightforward expansion of wired networks without configuration, offering reliable full-duplex operation across eight auto-negotiating RJ-45 ports. The device’s 16 Gbit/s switching capacity and 4,000-entry MAC table enable efficient local switching and reduced frame collisions in small networks. Compliance with IEEE 802.3az energy-efficient Ethernet reduces power consumption by scaling power to link activity, and the lightweight desktop form factor and plastic enclosure make it easy to position in constrained workspaces.

Suitable for

Small office wired networks
Home networks and media streaming
Connecting printers, IP phones and networked storage
Edge connectivity for compact workgroups
Temporary network expansion for events or meetings

Key specifications

Number of ports: 8 × RJ-45 10/100/1000 Mbps
Switching capacity: 16 Gbit/s
MAC address table: 4,000 entries
Standards supported: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az
Duplex mode: Full-duplex with auto-negotiation
Form factor: Desktop, plastic housing
Power: External 5 V DC input
Management: Unmanaged (plug-and-play)

How to use

Place the switch on a stable desktop surface near your router or network backbone and connect the supplied power adapter to a compatible 5 V DC outlet. Use standard Ethernet cables to link computers, printers, IP phones or other devices to the RJ-45 ports. The ports auto-negotiate connection speed and duplex, so no configuration is required; connected devices will start communicating once links are established. For best performance, connect uplink to your router or core switch using a Gigabit-capable port and avoid running cables near strong electromagnetic interference sources.

Usage recommendations

Use shielded or unshielded Cat5e or higher cabling for Gigabit links and ensure proper cable routing to minimise interference. Position the switch in a ventilated area to prevent heat buildup and place it on a non-conductive surface. For deployments requiring traffic segmentation, monitoring or PoE, consider a managed or PoE-capable switch instead.

Specifications

10G support:: No
Weight:: 0.15 kg
Basic switching RJ-45 Ethernet ports quantity:: 8
Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Product colour:: Black
Networking standards:: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u

All features

Power

Power source:: AC
DC input voltage:: 5
Power consumption (max):: 4 W
Power supply included:: Yes

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Storage temperature (T-T):: -40 - 70
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 5 - 90

Certificates

Certification:: FCC Class B, CE, RoHS

Logistics data

Harmonized System (HS) code:: 85176990

Network

Full duplex:: Yes
Networking standards:: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
10G support:: No
Copper ethernet cabling technology:: 10BASE-T, 10BASE-TX
Cable types supported:: Cat3, Cat4, Cat5, Cat6

Data transmission

MAC address table:: 4000 entries
Switching capacity:: 16 Gbit/s
Jumbo frames support:: Yes
Forwarding rate:: 11.9 Mpps
Packet buffer memory:: 1.5 MB

Weight & dimensions

Weight:: 0.15 kg
Height:: 22 mm
Width:: 53 mm
Depth:: 125 mm

Ports & interfaces

Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 8

Packaging content

Quick start guide:: Yes

Design

LED indicators:: Power, Activity, Link, Speed
Product colour:: Black
Housing material:: Plastic
