Circuit breaker 1P C 32A AC Kanlux 23160 — single-pole overcurrent protection

Kanlux 23160 is a single-pole (1P) circuit breaker with a C characteristic, rated for 32 A AC installations. It is intended for overcurrent and short-circuit protection in residential and light commercial distribution boards. The device is suitable for DIN-rail mounting and interrupts supply when current exceeds safe levels, balancing sensitivity to short-duration inrush currents and fast response to overloads.

Advantages

The Kanlux 23160 combines compact dimensions with a C-type tripping curve that allows normal motor or transformer inrush without nuisance trips while ensuring protection against sustained overloads and short circuits. Its single-pole design simplifies wiring and saves space in consumer units. The breaker is designed for easy installation on standard DIN rails and provides clear manual operation for switching and resetting.

Suitable for

• Residential circuit protection for lighting and socket circuits
• Small commercial or office installations with moderate inductive loads
• Distribution boards and consumer units with DIN-rail mounting
• Protection of individual circuits supplying motors, pumps, or transformers with typical inrush currents

When it may not be suitable

This single-pole breaker only interrupts the phase conductor and is not suitable where full multi-pole isolation of all live conductors is required, such as three-phase systems or installations needing combined neutral disconnection. It is designed for AC applications at its rated current; applications needing higher breaking capacity, special earth-leakage protection, or coordination with sensitive electronics might require different device types.

Key specifications

• Poles: 1 (single-pole)
• Nominal current: 32 A
• Tripping characteristic: C curve (moderate inrush tolerance)
• Application: AC distribution circuits
• Mounting: DIN-rail compatible

How to use

Mount the breaker on a standard DIN rail inside a distribution board and connect the phase conductor to the input terminal and the load to the output terminal according to local wiring regulations. Ensure the neutral conductor is routed and protected appropriately for the circuit. After correct wiring, switch the device to the ON position; the breaker will trip automatically under sustained overload or short-circuit conditions and can be reset manually once the fault is cleared. Follow national electrical codes and, if necessary, consult a qualified electrician for installation and coordination with other protective devices.

What to consider before purchase

• Compatibility with your distribution board and available DIN-rail space
• Appropriateness of a single-pole device for your wiring system and neutral handling
• Required breaking capacity and coordination with upstream or downstream protective devices
• Whether a different tripping characteristic or additional protection (RCD, RCBO) is needed

Usage recommendations

Use the Kanlux 23160 in circuits where a single-pole 32 A C-curve breaker provides adequate protection: lighting, general-purpose sockets, and circuits with moderate inductive loads. Periodically inspect connections for tightness and signs of overheating, and ensure proper labeling inside the distribution board for safe maintenance.
