LevelOne FSW-0508TX network switch FSW-0508TX

Name: LevelOne 5-Port Fast Ethernet Switch FSW0508TX
Brand: LEVELONE
SKU: 12027745
Price: 23.49 EUR
Availability: InStock

EcoFlow – energy without limits

Powerful EcoFlow stations for energy anywhere!

LevelOne 5-Port Fast Ethernet Switch

LevelOne FSW-0508TX network switch FSW-0508TX Photo 1

LevelOne FSW-0508TX network switch FSW-0508TX Photo 2

LevelOne FSW-0508TX network switch FSW-0508TX Photo 3

LevelOne FSW-0508TX network switch FSW-0508TX Photo 4

LevelOne FSW-0508TX network switch FSW-0508TX Photo 5

LevelOne FSW-0508TX network switch FSW-0508TX Photo 6

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

LevelOne 5-Port Fast Ethernet Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2048 entries, Switching capacity: 1 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x. Power connector: DC-in jack

Available for order: 10 pcs.

Warranty: 2 Years

SKU: 12027745

Charging device included

Learn more

Cheapest delivery:

Unisend LV

Pick-up points

Unisend LV

Cost

1.99 €

Deliver

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

02.10.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

07.10.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 €

Parcel couriers

Unisend LV / Venipak Pickup LV / Venipak Locker LV / DPD Paku skapis / Omniva LV / Latvijas Pasts pakomāts / Latvijas Pasts nodaļa

07.10.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The LEVELONE Switch LevelOne FSW-0508TX is an unmanaged 8-port Fast Ethernet switch that adds wired connectivity to small office and home networks. It offers eight 10/100 Mbps RJ45 ports for straightforward connection of computers, printers, VoIP phones and wireless access points. The device is designed for plug-and-play installation and does not require configuration, making it suitable for basic network expansion and simple segmentation tasks.

Advantages

The switch delivers reliable 10/100 Mbps connectivity across eight ports, enabling multiple devices to share a single network segment without complex setup. Its unmanaged design eliminates the need for configuration, reducing deployment time and maintenance. The compact form factor and low power consumption make it convenient for placement in small offices, network closets or home media cabinets. Auto MDI/MDIX support removes the need for crossover cables and simplifies cabling.

Suitable for

Small office LAN expansion and device consolidation
Home networks connecting PCs, NAS, printers and smart devices
Connecting IP phones and basic VoIP deployments
Adding wired ports for wireless access points or CCTV cameras (where 10/100 is sufficient)
Temporary network setups and meeting rooms requiring quick plug-and-play connectivity

Key specifications

Ports: 8 × 10/100 Mbps RJ45 autosensing Ethernet ports
Operation: Unmanaged, plug-and-play
Switching method: Store-and-forward
Auto-negotiation: 10/100 Mbps and full/half duplex support
Auto MDI/MDIX on all ports
Forwarding rate and MAC address table suitable for small LAN environments
Form factor: compact desktop metal/plastic housing (compact footprint)
Power: external/internal low-voltage power supply (external adapter typical)

How to use

Place the switch on a flat surface or mount it in a small equipment area near your network devices and power outlet. Connect each device to an available RJ45 port using standard Ethernet cables. Link one port to your router or upstream network device to provide network and internet access to connected devices. The switch will automatically detect link speed and duplex settings for each connection and begin forwarding traffic without user configuration. Check LED indicators on the front panel to verify link status and activity for each port.

Usage recommendations

For optimal performance, use quality Cat5e or Cat6 cables and connect the switch to a properly configured router for internet access. Avoid overloading the switch with high-throughput traffic beyond 100 Mbps per port; use this model for basic wired connectivity rather than high-bandwidth aggregation. Place the unit in a well-ventilated area and keep it away from direct heat sources and moisture.

Specifications

Power over Ethernet (PoE): The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.: No
Stackable: Devices can be placed on top of each other.: No
Rack mounting: The type of mounting that can position devices in a shelving system (rack).: No
Switching capacity: The data transfer capacity of the switch per second.: 1 Gbit/s
MAC address table: The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.: 2048 entries
10G support: The product can use Oracle 10G, which is a database management system introduced in 2003.: No
Installed SFP+ modules quantity: An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP that supports data rates up to 10 Gbit/s. The "SFP+ ports quantity" is the number of ports for SFP+ connections in a device.: 0
Installed SFP modules quantity: An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The "SFP ports quantity" is the number of ports for SFP connections in a device.: 0
Basic switching RJ-45 Ethernet ports type: The type/category of basic switching RJ-45 Ethernet ports (sockets).: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: The number of basic switching RJ-45 Ethernet ports (sockets).: 5
Switch type: What switch device has, managed or unmanaged.: Unmanaged
Networking standards: The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.: IEEE 802.3x, IEEE 802.3u, IEEE 802.3

All features

Logistics data

Harmonized System (HS) code:: 85176990
Country of origin: Country where the device is made. Aka Country of manufacture (COM).: China

Certificates

Certification:: FCC, CE, RoHS

Packaging data

Package weight: Weight of the packaged product.: 400 g
Package height: The distance from the top to the bottom of the packaging.: 156 mm
Package depth: The distance from the front to the back of the packaging.: 100 mm
Package width: The distance from one side of the packaging to the other.: 120 mm
AC adapter included:: Yes

Packaging content

Quick start guide: Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.: Yes

Weight & dimensions

Height: The measurement of the product from head to foot or from base to top.: 30 mm
Depth: The distance from the front to the back of something.: 69 mm
Width: The measurement or extent of something from side to side.: 125 mm

Operational conditions

Storage relative humidity (H-H):: 10 - 90
Operating relative humidity (H-H):: 5 - 90
Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.: -40 - 70
Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.: 0 - 40

Power over Ethernet (PoE)

Power over Ethernet (PoE): The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.: No

Power

Power consumption (typical): Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.: 2.5 W
Output current:: 1 A
Output voltage:: 5
AC input frequency:: 50 - 60
AC input voltage: The voltage of the AC electricity that is inputted into the product.: 100 - 240

Performance

Buffer size: The buffer is a temporary memory area in which data is stored while it is being processed or transferred, especially one used while streaming video or downloading audio. The buffer size is usually measured in MB (megabytes) or KB (kilobytes).: 48 KB

Design

LED indicators:: Power, Activity, Link
Product colour: The colour e.g. red, blue, green, black, white.: Black, Grey
Stackable: Devices can be placed on top of each other.: No
Rack mounting: The type of mounting that can position devices in a shelving system (rack).: No

Data transmission

Packet forwarding rate (10 Mbps):: 14880 pps
Packet forwarding rate (100 Mbps):: 148000 pps
Store-and-forward:: Yes
Switching capacity: The data transfer capacity of the switch per second.: 1 Gbit/s
MAC address table: The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.: 2048 entries

Network

Flow control support:: Yes
Auto MDI/MDI-X: A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.: Yes
Auto-negotiation:: Yes
Full duplex: A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.: Yes
Copper ethernet cabling technology:: 10BASE-T, 100BASE-TX
10G support: The product can use Oracle 10G, which is a database management system introduced in 2003.: No
Networking standards: The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.: IEEE 802.3x, IEEE 802.3u, IEEE 802.3

Ports & interfaces

Power connector:: DC-in jack
Installed SFP+ modules quantity: An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP that supports data rates up to 10 Gbit/s. The "SFP+ ports quantity" is the number of ports for SFP+ connections in a device.: 0
Installed SFP modules quantity: An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The "SFP ports quantity" is the number of ports for SFP connections in a device.: 0
Basic switching RJ-45 Ethernet ports type: The type/category of basic switching RJ-45 Ethernet ports (sockets).: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity: The number of basic switching RJ-45 Ethernet ports (sockets).: 5

Management features

Switch type: What switch device has, managed or unmanaged.: Unmanaged
