Managed Switch LevelOne 28-Port L2 Plus

Name: Managed Switch LevelOne 28-Port L2 IGU-2872
Brand: LEVELONE
SKU: 11049073
Price: 1007.99 EUR
Availability: InStock

Hot Deals at AiO.lv

Hurry and order now – up to 50% off!

Managed Switch LevelOne 28-Port L2 Plus Photo 3

Sale OUT! Discount 5%

You save: 58.50 €

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Usual Price: 1,066.49 €

Your Price:

The discount is valid from 03.06.2026 to 03.07.2026

Short description

The LevelOne 28-Port L2 Plus Managed Gigabit Fiber Industrial Switch features 4x 1.25/2.5GbE SFP, 16x 1.25GbE SFP, and 8x Gigabit SFP/RJ45 Combo ports. It supports a wide temperature range from -40°C to 80°C, making it ideal for harsh environments. With a switching capacity of 68 Gbit/s and a MAC address table of 16000 entries, it ensures efficient data handling. The switch also includes a redundant power supply and is rack mountable, providing reliability and flexibility for industrial networking.

Available at price 1,007.99 €: 4 pcs.

Total available for order: 20 pcs.

Warranty: 2 Years

SKU: 11049073

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

29.06.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 4.82 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

29.06.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

pay in 3 equal parts

today

0 €

afterward

3 mth. х 336 €

overpayment

0 €

All payment Methods Hide details

All payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment, Leasing for legal entities

36 months installment: from 28.00 euros per month

Leasing for legal entities: from 35.08 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The LevelOne IGU-2872 is a rugged L2+ managed industrial Ethernet switch designed for demanding industrial environments. It provides high-density fiber and copper connectivity with 16x 100/1000Base-X SFP ports, 8x Gigabit SFP/RJ45 combo ports and 4x 1G/2.5GBase-X SFP ports. Built for continuous operation, the switch supports redundant AC/DC power, advanced surge and ESD protection, and a wide operating temperature range from -40°C to +80°C in a fanless, IP40 rack-mount enclosure.

Advantages

The IGU-2872 delivers rapid network recovery through G.8032 ERPS with sub-20 ms failover and advanced Layer 2 functionality including VLAN, STP/RSTP/MSTP, Link Aggregation, QoS and IGMP Snooping. It supports robust management interfaces (Web, SNMP, CLI, Telnet, SSH) and simplifies maintenance with USB one-key configuration. Security features include 802.1X authentication, port isolation and ACL. The switch also offers IPv4/IPv6 static routing and DHCP server functions for enhanced Layer 3 capability.

Suitable for

Industrial automation networks and control systems
Railway, traffic control and utility networks
Large-scale manufacturing facilities and process control
Harsh-environment rack-mounted installations requiring fiber uplinks

Key specifications

Ports: 16× 100/1000Base-X SFP, 8× Gigabit SFP/RJ45 Combo, 4× 1G/2.5GBase-X SFP
Switching capacity: 68 Gbit/s
MAC address table: 16,000 entries
Protection: Surge protection 6 kV, ESD Air 15 kV / Contact 8 kV
Redundant power: AC/DC redundant power support
Operating temperature: -40°C to +80°C
Management: Web, SNMP, CLI, Telnet, SSH, USB one-key
Layer 2/3 features: VLAN, STP/RSTP/MSTP, G.8032 ERPS, Link Aggregation, QoS, IGMP Snooping, IPv4/IPv6 static routing, DHCP server
Enclosure: Fanless, IP40, rack-mountable

How to use

Install the IGU-2872 in a standard 19-inch rack and connect fiber or copper links to the appropriate SFP or RJ45 combo ports. Configure network parameters and security using the web interface, CLI, SNMP or SSH. Use the USB one-key function to apply saved configurations or perform firmware upgrades. For redundant power, connect both AC and DC power sources according to the installation manual.

Usage recommendations

Place the switch in a clean, ventilated rack position protected from direct moisture. Use approved SFP transceivers compatible with 1.25/2.5GbE and 1G SFP ports. Regularly back up configuration files and verify ERPS topology when deploying in ring architectures to ensure sub-20 ms recovery.

Specifications

Switch type:: Managed
Weight:: 4.14 kg
10G support:: No
Networking standards:: IEEE 802.3, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.1D
Product colour:: Black

All features

Ports & interfaces

USB 2.0 ports quantity:: 1
Console port:: RJ-45
Combo SFP ports quantity:: 8
SFP module slots quantity:: 20

Management features

Switch layer:: L2+
Quality of Service (QoS) support:: Yes
Web-based management:: Yes
System event log:: Yes
Switch type:: Managed

Network

Networking standards:: IEEE 802.3, IEEE 802.3z, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.1D
Flow control support:: Yes
Port mirroring:: Yes
Broadcast storm control:: Yes
Rate limiting:: Yes
Spanning tree protocol:: Yes
VLAN support:: Yes
10G support:: No
Copper ethernet cabling technology:: 1000BASE-T, 100BASE-TX, 10BASE-T
Port trunking:: Yes
Ethernet Ring Protection Switching (ERPS):: Yes
Virtual LAN features:: VLAN mapping, Stacked VLAN, Protocol-based VLAN, MAC address-based VLAN

Packaging content

Cables included:: LAN (RJ-45), AC
Quick start guide:: Yes
Rack mount kit:: Yes

Packaging data

Package weight:: 5293 g
Package depth:: 390 mm
Package height:: 95 mm
Package width:: 525 mm
Terminal block included:: Yes

Logistics data

Country of origin:: China
Master (outer) case height:: 408 mm
Master (outer) case width:: 535 mm
Master (outer) case gross weight:: 22522 g
Master (outer) case length:: 400 mm
Products per master (outer) case:: 4 pc(s)
Harmonized System (HS) code:: 851762

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Storage temperature (T-T):: -40 - 85
Operating temperature (T-T):: -40 - 80
Storage relative humidity (H-H):: 5 - 95

Power

Power source:: AC
Redundant power supply (RPS) support:: Yes
Surge protection voltage:: 6 kV
Surge protection:: Yes
AC input frequency:: 50/60
AC input voltage:: 100 - 240
DC input voltage:: 36 - 75
Power consumption (max):: 36 W
Power supply included:: Yes

Security

Security algorithms:: HTTPS, SSH
MAC address filtering:: Yes
Access Control List (ACL):: Yes
Authentication:: Port-based authentication, MAC-based authentication
Queue scheduling algorithms:: Weighted Round Robin (WRR)
Packet filtering:: Yes
MAC address entries:: Static MAC address entries, Dynamic MAC address entries

Design

Rack mounting:: Yes
LED indicators:: USB, System, Power
Product colour:: Black
International Protection (IP) code: Device protection rating against dust and water according to the international IP standard.: IP40

Technical details

Pallet gross width:: 1200 mm
Pallet gross length:: 800 mm
Master (outer) cases per pallet (air):: 14 pc(s)
Pallet height (air):: 1776 mm

Weight & dimensions

Weight:: 4.14 kg
Height:: 280 mm
Width:: 440 mm
Depth:: 45 mm

Performance

Mean time between failures (MTBF):: 200000 h
Fanless:: Yes

Data transmission

MAC address table:: 16000 entries
Switching capacity:: 68 Gbit/s
Jumbo frames support:: Yes
Forwarding rate:: 101.1 Mpps
Packet buffer memory:: 12 MB
Jumbo frames:: 10000

Power over Ethernet (PoE)

Power over Ethernet (PoE):: No

Protocols

IP Source Guard (IPSG):: Yes
IPv4 & IPv6 features:: IPv4/IPv6 access-control list (ACL)
