AV transmitter Lindy 70m Cat.6 HDMI 4K60 IR RS-232 HDBaseT

Type: Characteristics of the device.

AV transmitter

Special features:

Bi-directional IR, PoC

Bidirectional: Bidirectional script support is the capability of a computer system to correctly display bi-directional text. The term is often shortened to BiDi or bidi. Bi-directional text is text containing text in both text directionalities, both right-to-left (RTL) and left-to-right (LTR). It generally involves text containing different types of alphabets.

Yes

Chipset: Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance.

VS010

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

-20 - 60

Power requirements:

24VDC 1A

Wall mountable: The product can be mounted on (attached to ) a wall.

Yes

Connectivity technology: The technology that enables connectivity of the device, e.g. wired or wireless.

Wired

Maximum resolution: The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.

3840 x 2160

Bandwidth:

18 Gbit/s

Manual:

Yes

HDMI version:

2.0

HDCP: High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.

Yes

Maximum refresh rate:

60 Hz

HDMI in: Port (socket) for HDMI input.

1

Power source type: What the power source is.

DC

Cable types supported:

Cat6

Maximum transfer distance: The greatest distance over which the data/signal can be transferred.

70 m

RJ-45 output ports:

1

HDCP version:

2.2

Packaging content:

HDMI Transmitter Multi-country Power Supply (UK, EU, US & AUS) IR Emitter Cable, 1.5m IR Receiver Cable, 1.5m 3-Pin Terminal Block 2-Pin Terminal Block Lindy Manual

3.5 mm (1/8-inch) in:

Yes

RS-232 output ports:

1

3.5 mm (1/8-inch) out:

Yes

HDBaseT port:

Yes

Operating voltage (transmitter):

24 V

Infrared (IR) frequency range:

20 - 60

Extended display identification data (EDID):

Yes

RS-232 pass-through:

Yes

Features

Operating relative humidity (H-H):

20 - 90

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

0 - 40

Packaging data

Package weight: Weight of the packaged product.

540 g

Package depth: The distance from the front to the back of the packaging.

95 mm

Package height: The distance from the top to the bottom of the packaging.

133 mm

Package width: The distance from one side of the packaging to the other.

152 mm

Package type: The type of product package e.g. box.

Box

Quantity per pack:

1 pc(s)

Design

Certification:

California Proposition 65

Material: The material from which a thing is or can be made e.g. wood, plastic.

Metal

Product colour: The colour e.g. red, blue, green, black, white.

White, Black

On/off switch: The button which is pressed to switch the device on or off.

Yes

Other features

Output current:

1 A

Weight & dimensions

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

0.39 kg

Height: The measurement of the product from head to foot or from base to top.

86 mm

Width: The measurement or extent of something from side to side.

86 mm

Depth: The distance from the front to the back of something.

38.05 mm

Technical details

Sustainability compliance:

Yes

Sustainability certificates:

UKCA, RoHS, Federal Communications Commission (FCC), CE

Warranty period:

2 year(s)
