Certification:
-
IEC61300-3-4, IEC61300-3-6, IEC61300-2-2, IEC60794-2, IEC/PAS 61300-3-35, GR-326-CORE
-
Full duplex:
A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
-
Yes
-
Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-20 - 60
-
Cable length:
How long the cable is.
-
5 m
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Yellow
-
Connector material:
-
Ceramic
-
Country of origin:
Country where the device is made. Aka Country of manufacture (COM).
-
China
-
Package depth:
The distance from the front to the back of the packaging.
-
20 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
240 mm
-
Package width:
The distance from one side of the packaging to the other.
-
200 mm
-
Connector 1:
This is the first connector in the device.
-
LC
-
Connector 2:
This is the second connector in the device.
-
LC
-
Cable diameter:
The distance from one side of the cable to the other, with a straight line going through the middle of the cable.
-
3 mm
-
Insertion loss:
-
0.25 dB
-
Fiber mode structure:
-
Single-mode
-
Core diameter:
The diameter of the core, which is the material at the centre e.g. the metal in an electrical wire.
-
9 µm
-
Cladding diameter:
The diameter of the cladding, which is the material around the centre (core) e.g. the plastic coating in an electrical wire.
-
125 µm
-
Jacket material:
-
Low smoke zero halogen (LSZH)
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Quantity per pack:
-
1 pc(s)
-
Wavelengths supported:
-
1310
-
Fibre optic type:
The standardised properties of the fiber optic cable.
-
OS2
-
Return loss:
-
50 dB
-
Sustainability compliance:
-
Yes
-
Doesn't contain:
-
Halogen
-
Connector polish type:
-
UPC
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS
