Elbow internal MAGNAPLAST 90° D32/15 white (MPN 421008)

Internal elbow MAGNAPLAST 90° D32/15 in white is a compact plastic pipe fitting designed to connect and redirect pipes with nominal diameters 32 mm and 15 mm at a right angle. The fitting provides a smooth internal transition between larger and smaller plastic pipe sections and is intended for installations where direction change and diameter reduction are required, such as concealed plumbing runs, drainage branches and under-sink connections.

Advantages

The fitting offers a compact footprint and an internal bend that reduces external protrusion, making it suitable for tight installation spaces. Its white finish gives a neutral appearance in visible installations. The one-piece construction ensures consistent internal flow geometry and helps minimize turbulence at the change of diameter. The material selection provides resistance to common household water conditions and standard drainage fluids when used within recommended applications.

Suitable for

• Concealed plumbing and drainage installations in cabinets, walls and service voids
• Under-sink connections where a change from 32 mm to 15 mm pipe is required
• Drainage branches and waste lines that require a 90° direction change

Key specifications

• Connection configuration: internal elbow, 90° angle
• Pipe diameters: nominal 32 mm to 15 mm transition
• Color: white
• Material: plastic (suitable for typical plumbing and drainage use)
• Design: one-piece internal bend for compact installation

How to use

Select pipes with the correct nominal diameters and ensure pipe ends are clean and free of burrs. Insert the 32 mm and 15 mm pipes into the respective ends of the elbow until fully seated, following any manufacturer guidance for solvent welding, push-fit engagement or sealing method that applies to the chosen pipe system. Confirm alignment so the 90° turn directs flow as required, and secure adjoining pipe runs according to local plumbing practice and applicable standards.

Usage recommendations

Use the fitting only with compatible plastic pipe systems and installation methods; avoid exposure to chemicals or temperatures beyond the limits of common plumbing plastics. For concealed installations, verify accessible service points and test the assembled run for leaks before closing enclosures.
