Network switch MERCUSYS MS110CMP — 8-port PoE, 10 Gigabit RJ‑45 ports total, 115W PoE budget, desktop/wall-mountable, black

The MERCUSYS MS110CMP is a compact unmanaged network switch offering Gigabit connectivity and Power over Ethernet (PoE) for small offices and branch deployments. It provides ten RJ‑45 Gigabit Ethernet ports in a small desktop or wall‑mountable metal/plastic enclosure, including two general Gigabit copper ports and eight PoE‑capable ports with a total PoE budget of 115 W. The switch supports auto‑negotiation, Auto MDI/MDI‑X and IEEE 802.3x flow control. The unit accepts 220 V AC input (50 Hz), includes the external power supply and provides a 53.5 V DC output. Operating temperature range is 0–40 °C; storage and humidity limits apply. Ensure adequate ventilation during operation.

Advantages

The device combines Gigabit Ethernet performance with PoE power delivery in a compact form factor suitable for desktop placement or wall mounting. Built‑in auto‑negotiation and Auto MDI/MDI‑X simplify installation by removing the need for manual cable configuration, while IEEE 802.3x support helps maintain stable traffic flow. An included power supply and a 115 W PoE budget enable powering multiple PoE devices without additional injectors.

Suitable for

• Small office and branch networks
• Powering IP cameras and wireless access points via PoE
• Desktop use or fixed wall installation where space is limited

Key specifications

• Ports: 10 RJ‑45 Gigabit Ethernet ports (two general Gigabit copper ports, eight PoE‑capable ports)
• PoE total budget: 115 W
• Ethernet data rates: 10/100/1000 Mbit/s
• Networking features: Auto‑negotiation, Auto MDI/MDI‑X, IEEE 802.3x flow control
• Power input: 220 V AC, 50 Hz; DC output: 53.5 V (power supply included)
• Operating temperature: 0 to 40 °C; storage temperature: -40 to 70 °C
• Operating humidity: 10–90% RH; storage humidity: 5–95% RH
• Dimensions (H×D×W): 27 × 98 × 171 mm
• Color: Black

How to use

Place the switch on a stable desktop surface or mount it on a wall using appropriate screws and anchors. Connect the supplied AC power adapter to a 220 V AC mains outlet; confirm the power indicator is on. Connect network devices to the RJ‑45 ports using standard Ethernet cables; PoE‑capable ports will deliver power automatically to compatible devices. No configuration is required for basic switching and PoE operation—devices should establish links using auto‑negotiation.

Usage recommendations

Ensure the unit has adequate ventilation and is not enclosed in a tight cabinet during operation. Distribute the PoE load across ports to stay within the 115 W total budget and avoid overheating. Install the switch in an environment within the specified temperature and humidity ranges.
