Patch Panel BTR NETCOM 130857C-E RJ-45 Aluminium White Rack Mounting

The BTR NETCOM 130857C-E is a 3RU rack-mountable patch panel made of anodized aluminium with a white finish. It houses RJ-45 ports designed for Cat.6A networks and supports 10 GBit Ethernet (IEEE 802.3an). The module is certified by GHMT and complies with Class EA up to 500 MHz to ISO/IEC 11801 Ed.2.2 and related standards. Tested component performance reaches 600 MHz and link performance up to 800 MHz. The panel includes a label window and an integrated grounding rail with a 30 cm grounding cable; optional strain relief is possible using cable ties.

Advantages

The aluminium 3RU construction provides mechanical stability and reliable mounting in standard 3RU frames or surface-mounted housings using the included frame and adapters. Component testing and GHMT certification ensure compliance with Cat.6A and Class EA requirements, while higher-frequency testing offers headroom beyond standard certification. The panel supports Power over Ethernet (PoE, PoE+ and UPoE) and allows wires to be terminated on LSA insulation displacement connectors without untwisting pairs, simplifying installation and preserving performance. A label window enables clear port identification and an integrated grounding rail with cable ensures proper protection.

Suitable for

• 10 GBit Ethernet installations in data centers and wiring closets
• Cat.6A structured cabling for office and commercial buildings
• Environments requiring PoE, PoE+ or UPoE powered devices
• Rack-mounted network distribution and patching in 3RU spaces

Key specifications

• Form factor: 3RU module, anodized aluminium, white finish
• Connectors: RJ-45, termination via LSA insulation displacement (AWG 26/1–22/1)
• Standards and certification: GHMT certified; compliance with ISO/IEC 11801 Ed.2.2, DIN EN 50173-1, TIA/EIA-568-C.2
• Performance: Class EA up to 500 MHz; components tested to 600 MHz; links tested to 800 MHz
• Ethernet: Supports 10 GBit Ethernet (IEEE 802.3an)
• PoE: Suitable for PoE, PoE+ and UPoE
• Grounding: Grounding rail included with 30 cm grounding cable
• Labelling: Label window for identification labels

How to use

Mount the 3RU module in a compatible 3RU frame, surface-mounted housing, or on a top hat rail using the provided adapters. Route cables to the module and terminate conductors into the LSA insulation displacement connectors following the T568A colour code; pairs can be inserted without untwisting to maintain pair integrity. Secure cables with optional cable ties for strain relief and connect the grounding rail using the supplied 30 cm grounding cable to the building ground. Fit identification labels into the label window to mark ports clearly.

Usage recommendations

For best performance, follow ISO/TIA wiring standards when terminating and avoid excessive untwisting of pairs. Use appropriate cable management and strain relief to maintain channel performance and ensure the grounding connection is continuous and secure.
