Patch Panel METZ CONNECT 1502697424-E 1U LC-D Fiber Optic Black

The METZ CONNECT 1502697424-E 1U LC-D Fiber Optic Black patch panel is a rack-mountable module designed to centralize and organize fiber optic terminations in a standard 19-inch cabinet. Constructed from durable metal with a black and grey finish, the unit accommodates LC-D duplex connections and supports a variety of fiber cable types. Its compact 1U profile and measured depth allow installation in network racks where space efficiency and orderly cable management are required.

Advantages

This patch panel provides a secure, fixed mounting point for fiber connections while protecting terminations from dust and mechanical strain. The metal housing offers stability and grounding potential in professional environments. The LC-D duplex interface enables high-density deployment of single-mode or multimode fiber, reducing rack space usage compared with larger connector types. Front-access ports simplify moves, adds, and changes without disturbing rear cable runs.

Suitable for

• Data centers and server rooms requiring organized fiber distribution
• Telecommunications closets and wiring cabinets in commercial buildings
• Network nodes for campus or enterprise fiber backbones
• Environments needing compact 1U fiber termination and patching

Key specifications

• Form factor: 1U rack-mount panel compatible with 19-inch cabinets
• Connector type: LC-D duplex fiber ports
• Material: metal housing for mechanical protection
• Color: black and grey finish for professional appearance
• Dimensions (W×H×D): 482.6 mm × 44.5 mm × 244 mm
• Port density: supports multiple LC duplex terminations for high-density layouts

How to use

Mount the panel into a 19-inch rack occupying a single U of height, securing it with appropriate rack screws. Route fiber cables to the rear entry points and terminate or connect patch cords to the LC-D ports at the front. Ensure all fiber connections are clean and inspected before mating to prevent signal loss. Use strain relief and cable management accessories to maintain bend radii and reduce stress on connectors. Label ports and patch cords as required for easy identification.

Usage recommendations

For reliable optical performance, perform connector cleaning and inspection before each connection, maintain minimum bend radii for installed fibers, and use compatible LC duplex patch cords. In installations subject to vibration or movement, add additional rear support and secure cable runs to prevent connector strain.
