TP-Link RE315 AC1200 Mesh Wi-Fi Range Extender

Type: Characteristics of the device.

Network repeater

Wi-Fi standards: The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Security algorithms: Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.

64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK

Browser supported: List of supported browsers for this product.

Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0

Mac compatibility: Product can be used with Apple Mac software and/or hardware.

Yes

Antenna type: Type of antenna, also known an aerial, e.g. external, internal.

External

Wi-Fi data rate (max):

867

Wi-Fi: Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.

Yes

WLAN data transfer rates supported:

300

Quick start guide: Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.

Yes

Antennas quantity:

2

Windows operating systems supported: Windows vesions wich can be used with the device.

Yes

Mac operating systems supported: Mac operating systems e.g. OS X can be used with the device.

Yes

Linux operating systems supported: 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)

Yes

AC input frequency:

50/60

AC input voltage: The voltage of the AC electricity that is inputted into the product.

100 - 240

WPS push button:

Yes

Wi-Fi band: The frequency bands the product features.

Dual-band (2.4 GHz / 5 GHz)

Ethernet LAN interface type: The characteristics of the Ethernet LAN interface.

Fast Ethernet

Top Wi-Fi standard: Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 5 (802.11ac)

Transmitting power (CE):

2.4 GHz ≤20dBm, 5 GHz ≤30dBm

Logistics data

Harmonized System (HS) code:

85176990

Packaging data

Package type: The type of product package e.g. box.

Box

Package weight: Weight of the packaged product.

260 g

Package height: The distance from the top to the bottom of the packaging.

156.5 mm

Package depth: The distance from the front to the back of the packaging.

89 mm

Package width: The distance from one side of the packaging to the other.

121.5 mm

Packaging content

Quantity per pack:

1 pc(s)

Weight & dimensions

Height: The measurement of the product from head to foot or from base to top.

124.1 mm

Depth: The distance from the front to the back of something.

35 mm

Width: The measurement or extent of something from side to side.

89 mm

Operational conditions

Storage relative humidity (H-H):

5 - 90

Operating relative humidity (H-H):

10 - 90

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

-40 - 70

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

0 - 40

Certificates

Certification:

CE, RoHS

Compliance certificates: Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.

CE, RoHS

Power

Power consumption (max): The maximum amount of power used by the device.

9.5 W

Features

Product colour: The colour e.g. red, blue, green, black, white.

White

Performance

Ethernet LAN (RJ-45) ports: Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

1

Cabling technology: Type of cable technology performance.

10/100Base-T(X)

Networking standards: The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.

IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g

Network

Data transfer rate: Rate at which data can be transferred, usually measured in units per second. May vary with network configurations.

867 Mbit/s

Ethernet LAN data rates: The different speed levels of the Ethernet LAN connection.

10, 100

Management features

Reset button:

Yes

Design

LED indicators:

Y
