Certification:
-
CE
-
Full duplex:
A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
-
Yes
-
Package weight:
Weight of the packaged product.
-
400 g
-
Material:
The material from which a thing is or can be made e.g. wood, plastic.
-
Steel, Polyoxymethylene (POM)
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
10 - 45
-
Cable length:
How long the cable is.
-
2.5 m
-
Cable type:
Type of cable e.g. electicity cable, optical cable.
-
OFC
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
100 Gbit/s
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Yellow
-
Connector material:
-
Ceramic
-
Country of origin:
Country where the device is made. Aka Country of manufacture (COM).
-
Hungary
-
Package depth:
The distance from the front to the back of the packaging.
-
690 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
50 mm
-
Package width:
The distance from one side of the packaging to the other.
-
50 mm
-
Connector 1:
This is the first connector in the device.
-
LC
-
Connector 2:
This is the second connector in the device.
-
LC
-
Insertion loss:
-
0.1 dB
-
Ethernet interface type:
-
100 Gigabit Ethernet, 40 Gigabit Ethernet, 10 Gigabit Ethernet
-
Fiber mode structure:
-
Single-mode
-
Core diameter:
The diameter of the core, which is the material at the centre e.g. the metal in an electrical wire.
-
9 µm
-
Cladding diameter:
The diameter of the cladding, which is the material around the centre (core) e.g. the plastic coating in an electrical wire.
-
125 µm
-
Jacket material:
-
Low smoke zero halogen (LSZH)
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Quantity per pack:
-
1 pc(s)
-
Wavelengths supported:
-
1550, 1310
-
Fibre optic type:
The standardised properties of the fiber optic cable.
-
OS2
-
Connector polish type:
-
PC
