PoE splitter PLANET POE-161S — 5V/12V, Gigabit

Name: PoE splitter PLANET POE-161S, 52–56V POE-161S
Brand: PLANET
SKU: 4969581
Price: 41.49 EUR
Availability: InStock

JBL – powerful sound always with you

JBL speakers and headphones for pure and deep sound!

PoE splitter PLANET POE-161S, 52–56V DC input, 5V/12V DC output, Gigabit Ethernet, white

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

PLANET POE-161S is a Power over Ethernet (PoE) splitter that separates DC power from Gigabit Ethernet data. It supports IEEE 802.3/802.3u/802.3ab and PoE standards IEEE 802.3af/at, works with Cat6 cabling and 10/100/1000Base-T(X). Input voltage is 52–56 V DC and it provides selectable DC outputs of 5 V or 12 V. Compact plastic housing in white; certified to FCC Part 15 Class A and CE.

Available at price 41.49 €: 27 pcs.

Total available for order: 56 pcs.

Warranty: 2 Years

SKU: 4969581

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

03.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

03.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

08.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.11 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

08.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

Available for private customers at price 52.99 €: 27 pcs.

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

PLANET POE-161S is a Power over Ethernet (PoE) splitter designed to separate DC power from Gigabit Ethernet data for devices that require 5 V or 12 V DC input. The device supports IEEE 802.3/802.3u/802.3ab Ethernet standards, is compatible with IEEE 802.3af/at PoE sources and works over Cat6 cabling with 10/100/1000Base-T(X) speeds. The splitter accepts a 52–56 V DC PoE input and provides a selectable DC output (5 V or 12 V) via an internal DIP switch. Housed in a compact white plastic enclosure, the unit is certified to FCC Part 15 Class A and CE standards.

Advantages

The POE-161S enables single-cable deployment by extracting power and data from an IEEE 802.3at PoE Plus source and offering up to 25.5 W input power capability for downstream devices. It supports Gigabit Ethernet throughput in passive duplex mode while providing a user-selectable 5 V or 12 V DC output, reducing the need for separate power supplies and additional electrical cabling at the powered device location. The compact form factor simplifies installation in constrained spaces and the device is suitable for use with PoE injectors, PoE switches and PoE media converters.

Suitable for

PTZ network cameras and speed dome cameras
Color touch-screen or video/VoIP telephones
High-power wireless access points and multi-channel APs
Network devices requiring 5 V or 12 V DC but lacking native PoE input

Key specifications

PoE input voltage: 52–56 V DC
PoE standard: IEEE 802.3af/802.3at compliant (supports PoE Plus)
Maximum input power: up to 25.5 W (IEEE 802.3at PoE Plus)
DC output options: selectable 5 V DC or 12 V DC via DIP switch
Ethernet speed: 10/100/1000 Mbps (Gigabit Ethernet)
Cabling: compatible with Cat5e/Cat6 twisted pair
Housing: compact white plastic enclosure
Standards & certifications: FCC Part 15 Class A, CE

How to use

Connect an IEEE 802.3at PoE Plus source (PoE switch, injector or media converter) to the POE-161S via a standard RJ45 Ethernet cable. Set the internal DIP switch to select the required DC output voltage (5 V or 12 V). Use the provided DC output connector to supply the powered device with the selected DC voltage while the Ethernet RJ45 port continues to carry data. Keep the injector/switch within the standard 100-meter Ethernet distance from the splitter to ensure reliable power and data delivery.

Usage recommendations

Use the POE-161S with IEEE 802.3at-compliant PoE injectors or switches to guarantee sufficient input power for high-consumption devices. Verify the target device's voltage and current requirements before selecting 5 V or 12 V output, and ensure cabling and connectors are in good condition to maintain Gigabit performance and stable power delivery.

Specifications

Ethernet LAN (RJ-45) ports:: 2
Weight:: 0.108 kg
Product colour:: White

All features

DC output voltage:: -12V, -5V
DC-out jack:: Yes

Operational conditions

Operating relative humidity (H-H):: 5 - 95
Storage temperature (T-T):: -10 - 70
Operating temperature (T-T):: 0 - 50

Power

Input voltage:: 52 - 56 DC

Certificates

Certification:: FCC Part 15 Class A, CE

Network

Cabling technology:: 10/100/1000Base-T(X)
Networking standards:: IEEE 802.3at, IEEE 802.3u, IEEE 802.3af, IEEE 802.3ab, IEEE 802.3
Power over Ethernet (PoE):: Yes
Cable standard:: Cat6

Ports & interfaces

Ethernet LAN (RJ-45) ports:: 2
RJ-45 input ports:: 1
RJ-45 output ports:: 1

Features

Plug and Play:: Yes
LED indicators:: Y
Wall mountable:: Yes
Product colour:: White
Housing material:: Plastic

Weight & dimensions

Weight:: 0.108 kg
Height:: 25 mm
Width:: 95 mm
Depth:: 70 mm
