header-product Directional antenna QuWireless AX12M
245.99 €

Directional antenna QuWireless AX12M

Directional antenna QuWireless AX12M Photo 1
Directional antenna QuWireless AX12M Photo 2
Directional antenna QuWireless AX12M Photo 3
Directional antenna QuWireless AX12M Photo 4
Directional antenna QuWireless AX12M Photo 1
Directional antenna QuWireless AX12M Photo 2
Directional antenna QuWireless AX12M Photo 3
Directional antenna QuWireless AX12M Photo 4
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Directional antenna QuWireless AX12M

{{email}}
You keep track of price changes

Directional antenna QuWireless AX12M

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

The QuWireless AX12M is a high-performance directional antenna with a gain of 6 dBi. It operates across multiple frequency bands (0.694-0.96/1.7-2.2/2.2-2.7; 2.4-2.5/4.7-6 GHz) and features vertical polarization. Designed for PoE/LAN connections, it measures 392 mm in width and depth, and 99 mm in height. Ideal for enhancing network connectivity in various applications.
Available for order: 5 pcs.
Warranty: 2 Years
SKU: 3664482
Manufacturer: QuWireless
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
14.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
17.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 € (Weight: 3.70 kg)
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
17.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
0 credit

pay in 3 equal parts

today

0 €

afterward

3 mth. х 82 €

overpayment

0 €

All payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment
36 months installment: from 6.83 euros per month
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The QuWireless AX12M is a directional multi-band antenna system that combines LTE MIMO capability with integrated Wi‑Fi, GPS and Bluetooth reception. With a maximum gain of 6 dBi and vertical polarization, it covers a wide range of cellular and wireless frequencies (0.694–0.96 / 1.7–2.2 / 2.2–2.7; 2.4–2.5 / 4.7–6 GHz) to support improved link performance in outdoor installations. The unit is supplied in a weather-resistant enclosure sized 392 mm (width and depth) by 99 mm (height) and is intended for use with PoE/LAN connections. The antenna assembly accepts installation of Teltonika RUTX12 or RUTX14 routers inside the enclosure to create an integrated all‑in‑one solution for mobile and fixed network deployments.

Advantages

The AX12M integrates MIMO 4x4 multi‑band LTE directional elements together with dual‑band Wi‑Fi omni elements plus GPS and Bluetooth reception, reducing the need for multiple separate antennas and simplifying outdoor deployment. Its multi‑band coverage enables compatibility with numerous cellular and wireless bands, while the 6 dBi gain improves directional link quality. The enclosure supports mounting a compatible router internally, providing a compact, weather-resistant package suitable for industrial, CCTV and hotspot applications.

Suitable for

  • Outdoor cellular connectivity for mobile and fixed installations
  • Industrial and remote site internet access
  • CCTV and surveillance backhaul links
  • Public hotspots and venue wireless coverage
  • Installations requiring integrated router and antenna enclosure

Key specifications

  • Frequency coverage: 0.694–0.96 / 1.7–2.2 / 2.2–2.7; 2.4–2.5 / 4.7–6 GHz
  • Antenna gain: up to 6 dBi
  • Polarization: vertical
  • Integrated antenna types: LTE MIMO directional (4x), Wi‑Fi dual‑band omni, GPS, Bluetooth
  • Supports internal installation of compatible routers (designed for Teltonika RUTX12/RUTX14)
  • PoE/LAN connectivity support
  • Dimensions (approx.): 392 mm width × 392 mm depth × 99 mm height
  • Colour: white
  • Weight: 3.7 kg

How to use

Mount the AX12M at an appropriate outdoor location with clear line of sight toward the target cellular or Wi‑Fi infrastructure. Install the compatible router inside the enclosure following the manufacturer’s instructions for securing the device and routing PoE/LAN cabling through the weatherproof entry points. Connect LTE modem SMA leads or MIMO connections as required and attach any external connectors for GPS or Bluetooth antennas if applicable. Ensure cable glands and seals are tightened to maintain the enclosure’s weather resistance. After installation, verify signal levels and adjust orientation to optimize directional LTE performance.

Usage recommendations

For best results, place the antenna at elevated positions and avoid obstructions. When used with a compatible router installed inside the enclosure, verify that the router’s antenna connections match the AX12M’s connector layout and that all seals are properly tightened to preserve weather protection. Periodically check connectors and mounting hardware for corrosion or loosening in harsh outdoor conditions.

Specifications

Frequency band:
0.694-0.96/1.7-2.2/2.2-2.7; 2.4-2.5/4.7-6
Antenna gain level (max):
6 dBi
Weight:
3.7 kg
Product colour:
White
All features

Packaging content

Quantity per pack:
1 pc(s)

Operational conditions

Operating temperature (T-T):
-40 - 75

Features

Antenna type:
Directional antenna
Product colour:
White
Mounting:
Wall/Pole
Compatible products:
RUTX12, RUTX14
Purpose:
Indoor & outdoor
Antenna connector type:
PoE/LAN
Polarization:
Vertical polarization
Voltage Standing Wave Ratio (VSWR):
1.3 - 1.8
Housing material:
Aluminium, Acrylonitrile butadiene styrene (ABS)
International Protection (IP) code: Device protection rating against dust and water according to the international IP standard.
IP67

Performance

Frequency band:
0.694-0.96/1.7-2.2/2.2-2.7; 2.4-2.5/4.7-6
Antenna gain level (max):
6 dBi
Impedance:
50 Ω
Gain:
4 dBi
Horizontal beam width:
90 °
Vertical beam width:
90 °
Antenna gain (2.4 GHz):
6 dBi
Antenna gain (5 GHz):
7 dBi
Horizontal beam width (2.4 GHz):
360 °
Horizontal beam width (5 GHz):
360 °
Vertical beam width (5 GHz):
25 °
Vertical beam width (2.4 GHz):
25 °

Weight & dimensions

Weight:
3.7 kg
Height:
99 mm
Width:
392 mm
Depth:
392 mm

Logistics data

Country of origin:
Poland
