Panel-mount Dual USB Charger ram mount 560027 — USB-A and USB-C, LED display, 200 mm bare-wire cable

The ram mount Panel-mount Dual USB Charger 560027 is a compact built-in charging module that provides one USB-A and one USB-C port for simultaneous device charging. Designed for flush installation in dashboards, control panels, furniture, caravans, motorhomes and boats, the unit includes a 7-segment LED display that shows onboard voltage and a push button to activate the display. The charger features a 200 mm bare-wire cable for direct wiring into 12–24 V DC systems and is suitable for panels up to 17 mm thick with an installation diameter of 27 mm.

Advantages

The dual-port layout with USB-A and USB-C provides broad compatibility with smartphones, tablets, rechargeable lighting and other USB-powered devices. High-speed charging support (Quick Charge and Power Delivery protocols) allows up to 18 W per port for faster charging. Integrated protection against short circuits, overheating and overvoltage increases safety in vehicle and marine environments. The compact front diameter and flush-mount design enable tidy, space-saving installations while the LED voltage display gives a clear overview of system voltage without additional meters.

Suitable for

• Installation in vehicle dashboards, RVs, caravans and boats
• Built-in charging points in furniture, control panels and workstations
• Charging smartphones, tablets, rechargeable lamps and small USB devices
• Direct wiring into 12–24 V DC electrical systems

Key specifications

• Input voltage: 12–24 V DC
• Output power: 2 × 18 W (per port up to 18 W depending on protocol)
• USB-A outputs: 5.0 V up to 3 A (15 W), 9.0 V up to 2 A (18 W), 12.0 V up to 1.5 A (18 W); supports QC2.0/QC3.0/FCP/AFC/SFCP/BC1.2/DCP/SCP/PE protocols
• USB-C outputs: 5.0 V up to 3 A (15 W), 9.0 V up to 2 A (18 W), 12.0 V up to 1.5 A (18 W); supports PD3.0 PPS, QC3.0–4+, AFC, FCP, BC1.2, DCP, SCP, PE protocols
• Standby current: 5–7 mA
• Operating temperature range: -20 °C to +80 °C; storage: -40 °C to +90 °C
• Dimensions: front diameter 36 mm; installation diameter 27 mm; depth 45.7 mm; fits panel thickness up to 17 mm
• Weight: approximately 30 g
• Integrated safety functions: short-circuit, overtemperature and overvoltage protection
• 7-segment LED voltage display with push-button activation
• Connection: 200 mm open bare-wire cable for direct wiring
• Standards & approvals: CE, UKCA, EN and automotive EMC and safety standards

How to use

Drill a 27 mm installation hole in a panel up to 17 mm thick and insert the charger until the front rim sits flush with the surface. Connect the bare-wire cable to the vehicle or equipment 12–24 V DC supply following correct polarity and secure all connections with appropriate terminals or shrink tubing. Press the push button to view the onboard voltage on the LED display for approximately one minute; plug USB devices into the USB-A or USB-C socket to start charging. Ensure wiring is protected and fused according to the electrical system requirements before use.

Usage recommendations

Use high-quality USB cables that support the required fast-charge protocol for best charging performance. Install the unit in a location with reasonable ventilation and avoid mounting near direct heat sources. For marine or outdoor-exposed installations, consider using an optional dust cover and ensure connections are sealed against moisture. Verify fuse ratings and wiring cross-sections to match the input current and protect the vehicle or equipment electrical system.
