Fibre optic cable Sacon LSD41100020

The Sacon LSD41100020 is a 2-meter OM4 fibre optic cable with SC connectors on both ends and a 50 µm core diameter, designed for full duplex data transmission. Built for environments where high-bandwidth, low-loss optical links are required, this cable supports InfiniBand and other high-speed networking applications. The product combines standardized OM4 multimode fiber characteristics with SC terminations to provide consistent optical performance over short to medium link distances.

Advantages

The cable provides high bandwidth and low attenuation typical of OM4 multimode fiber, enabling reliable high-speed transfers. With SC connectors on both ends, it offers a secure, easy-to-install interface compatible with equipment that uses SC ports. The 2 m length balances reach and manageability in rack, cabinet, or equipment-to-equipment connections. Full duplex capability allows simultaneous bidirectional communication for balanced network architectures.

Suitable for

• InfiniBand interconnects and high-performance computing links
• Data center short-range uplinks between switches and patch panels
• Server-to-switch or shelf-to-shelf fiber connections
• Telecommunications equipment with SC multimode ports

Key specifications

• Fiber type: OM4 multimode
• Core diameter: 50 µm
• Connector type: SC — on both ends
• Length: 2 meters
• Transmission mode: Full duplex

How to use

Before installation, ensure both network devices use SC multimode ports and that link budgets match OM4 fiber parameters. Remove protective caps from the SC connectors and avoid touching the polished endfaces. Route the cable avoiding tight bends and mechanical stress; maintain bend radius recommended for multimode fiber during installation. Insert each SC connector into the corresponding SC adapter or port until it clicks or seats firmly, verifying full duplex orientation if required. After connection, check link status and perform loss or continuity testing as part of commissioning.

Usage recommendations

Store and handle the fiber cable in a clean environment; use connector dust caps when unplugged, avoid exceeding bend radius, and perform optical power or insertion loss tests after installation to verify performance in OM4-based systems.
