Schneider Electric Acti9 C120N Miniature Circuit Breaker 1P 100A B-Curve 10kA

The Schneider Electric Acti9 C120N is a high-performance 1-pole miniature circuit breaker engineered to provide robust protection for electrical distribution systems. Designed for demanding environments, this device offers a rated current of 100A and a B-curve tripping characteristic, ensuring precise response to overloads and short circuits. With a breaking capacity of 10kA, it is built to maintain safety and operational reliability in both industrial and commercial power networks.

Advantages

This circuit breaker stands out due to its high level of durability and precision in electrical fault detection. The Acti9 C120N series is recognized for its ability to withstand harsh operating conditions while maintaining consistent performance. Its design facilitates efficient power distribution management, reducing the risk of equipment damage and ensuring that electrical installations remain protected against unexpected surges or system failures.

Suitable for

• Industrial power distribution panels
• Commercial building electrical systems
• Protection of high-current electrical circuits
• Infrastructure projects requiring reliable circuit breaking

When it may not be suitable

This device is not intended for residential applications where lower current ratings are typically required. It is also not suitable for DC electrical systems, as it is specifically designed for AC power distribution.

Key specifications

• Number of poles: 1
• Rated current: 100A
• Tripping curve: B
• Breaking capacity: 10kA
• Technology: Thermal-magnetic

How to use

The device is designed for DIN rail mounting within a standard electrical distribution board. Installation should be performed by a qualified electrician in accordance with local electrical regulations. Ensure that the supply cables are correctly sized for a 100A load and securely tightened to the terminals to prevent overheating. Once installed, the toggle switch allows for manual operation to disconnect or reconnect the circuit as needed.

What to consider before purchase

• Verify that the 100A rating matches your circuit requirements
• Ensure the B-curve characteristic is appropriate for your specific load type
• Check that your distribution board has sufficient space for a 1-pole module
• Confirm compatibility with AC power systems

Usage recommendations

Regularly inspect the terminal connections for tightness and ensure the device is free from dust or debris to maintain optimal performance and safety.
