Secomp CL5708MW rack console 17.3" LCD

Name: Rack console Secomp CL5708MW 17.3" CL5708MW D
Brand: Secomp
SKU: 11657047
Price: 1307.49 EUR
Availability: InStock

JBL – powerful sound always with you

JBL speakers and headphones for pure and deep sound!

Rack console Secomp CL5708MW 17.3" (43.9 cm) LCD 1920×1080, USB/PS/2 keyboard & mouse, VGA, 1U, black

Secomp CL5708MW rack console 17.3" LCD Photo 1

Secomp CL5708MW rack console 17.3" LCD Photo 2

Secomp CL5708MW rack console 17.3" LCD Photo 3

Secomp CL5708MW rack console 17.3" LCD Photo 4

Secomp CL5708MW rack console 17.3" LCD Photo 5

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

Secomp CL5708MW rack console with a 17.3" (43.9 cm) LCD panel and 1920×1080 resolution provides integrated keyboard and touchpad control for server cabinets. It features USB and PS/2 ports for keyboard and mouse, a VGA video input, German QWERTZ keyboard layout, metal and plastic 1U housing, and typical power consumption of 15.4 W. Ideal for local server management in data centers and IT rooms.

Available for order: 11 pcs.

Warranty: 2 Years

SKU: 11657047

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

30.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

30.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

03.07.2026 {{selectedOffer.courierDeliveryString}}

From 10.86 € (Weight: 13.39 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Locker / Latvijas Pasts nodaļa

03.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

pay in 3 equal parts

today

0 €

afterward

3 mth. х 435.83 €

overpayment

0 €

All payment Methods Hide details

All payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment, Leasing for legal entities

36 months installment: from 36.32 euros per month

Leasing for legal entities: from 45.5 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Secomp CL5708MW Slideaway is a 1U rack-mountable LCD KVM console that integrates a 17.3" (43.9 cm) 1920×1080 LED-backlit monitor, USB/PS/2 keyboard and mouse (QWERTZ German layout), and touchpad into a sliding housing for server cabinet use. The CL5708 series allows a single console to control 8 or 16 computers and supports daisy-chaining up to 31 additional units, enabling control of up to 256 computers from one console. The unit supports VGA video input and is built from metal and plastic in a black finish. Typical power consumption is around 15.4 W.

Advantages

The CL5708MW provides a space-saving integrated solution for local server management by combining keyboard, video and mouse in a single 1U sliding housing with a high-resolution 17.3" monitor. It supports both USB and PS/2 interfaces and offers automatic interface detection and keyboard/mouse emulation to ensure smooth switching and simultaneous booting of multiple computers. The console supports daisy-chaining for large installations and includes on-screen display (OSD), front-panel controls, hotkeys and firmware upgrade capability across chained units.

Suitable for

Local server management in data centers and server rooms
Rack-mounted network closets and IT infrastructure cabinets
Environments requiring centralized access to multiple servers (small to medium-sized installations)

Key specifications

Model: Secomp CL5708MW
LCD panel: 17.3" (43.9 cm) LED-backlit, 1920 × 1080 pixels, 250 cd/m², 800:1 contrast
Form factor: 1U rack-mountable Slideaway housing
Interfaces: USB and PS/2 for keyboard/mouse; VGA video input
Keyboard layout: QWERTZ (German)
Materials / color: Metal and plastic, black
Control: Front-panel buttons, hotkeys, multilingual OSD
Expandable: Daisy-chain up to 31 additional KVMs (control up to 256 computers)
Security: Two-level password support (one admin, four users)
Power consumption: Typical ~15.4 W

How to use

Install the CL5708MW into a 1U rack space and connect the console to servers using compatible KVM cables for USB or PS/2 keyboard and mouse and VGA video. Use the front-panel buttons, hotkeys or OSD menu to select target servers; the unit auto-detects PS/2 and USB interfaces and emulates keyboard and mouse to maintain operation during server boot. For larger setups, daisy-chain additional compatible CL5708 units using the provided daisy-chain ports to expand control up to 256 systems from the same console.

Usage recommendations

For reliable operation, use high-quality VGA and KVM cables, confirm keyboard layout settings in the OSD to match the QWERTZ physical layout, and keep firmware updated across all daisy-chained units when applying upgrades.

Specifications

Keyboard port type:: USB, PS/2
Mouse port type:: USB, PS/2
Video port type:: VGA
Number of computers controlled:: 256
Weight:: 13.39 kg
Product colour:: Black

All features

Pixel pitch:: 0.199 x 0.199
Contrast ratio (typical):: 800:1
Viewing angle, horizontal:: 170 °
Viewing angle, vertical:: 170 °
AC adapter input voltage:: 100 - 240
AC adapter frequency:: 50/60
Display brightness:: 250 cd/m²
Response time:: 16 ms
Display resolution:: 1920 x 1080
AC (power) in:: Yes
On/off switch:: Yes
Built-in touchpad:: Yes
Supported resolutions:: 1280 x 1024 @75 Hz; DDC2B, 1920 x 1200 @ 60 Hz
Built-in KVM switch:: Yes
KVM switch ports quantity:: 8

Design

Rack mounting:: Yes
Material:: Plastic, Metal
Hot keys:: Yes
LED indicators:: Y
Product colour:: Black
Rack capacity:: 1U
Keyboard language:: German
Push button:: Yes

Ports & interfaces

VGA (D-Sub) ports quantity:: 8
Keyboard port type:: USB, PS/2
Mouse port type:: USB, PS/2
Video port type:: VGA
Number of computers controlled:: 256
Console port:: SPHD-18

Operational conditions

Operating relative humidity (H-H):: 0 - 85
Storage temperature (T-T):: -20 - 60
Operating temperature (T-T):: 0 - 40

Other features

Keyboard layout:: QWERTZ

Display

Display:: LCD
Display diagonal: iagonal of the visible part of the screen expressed in centimeters and inches.: 17.3 "
On Screen Display (OSD):: Yes

Performance

Maximum resolution:: 1920 x 1200
Hot-Plug support:: Yes
Daisy chain:: Yes
Auto scan delay (min):: 1 s
Auto scan delay (max):: 255 s

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.: 15.4 W
Input current:: 1

Logistics data

Country of origin:: China
Master (outer) case height:: 135 mm
Master (outer) case width:: 668 mm
Master (outer) case gross weight:: 17100 g
Master (outer) case length:: 833 mm

Weight & dimensions

Weight:: 13.39 kg
Height:: 44 mm
Width:: 689.2 mm
Depth:: 480 mm

Packaging data

Package weight:: 17100 g
Package depth:: 833 mm
Package height:: 135 mm
Package width:: 668 mm

Packaging content

Cables included:: AC, KVM
Manual:: Yes
Quick installation guide:: Yes
Rack mount kit:: Yes

Sustainability

Compliance certificates:: RoHS

System requirements

Windows operating systems supported:: Y
Mac operating systems supported:: Y
Linux operating systems supported:: Y
