Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Snagless cable boot:
-
Yes
-
Total Power over Ethernet (PoE) budget:
-
100 W
-
Power over Ethernet (PoE) type supported:
-
PoE++ (4PPoE)
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Frequency:
-
250 MHz
-
Data transfer rate:
Rate at which data can be transferred, usually measured in units per second. May vary with network configurations.
-
1000 Mbit/s
-
AWG wire size:
-
28
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3bt
-
Ethernet interface type:
-
Fast Ethernet, Gigabit Ethernet
-
Cabling technology:
Type of cable technology performance.
-
10/100/1000Base-T(X)
-
Conductor material:
-
Copper
-
Conductor type:
-
Stranded
-
Cable shape:
-
Round
-
Jacket material:
-
Low smoke zero halogen (LSZH)
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Connector 2:
This is the second connector in the device.
-
RJ-45
-
Connector 1:
This is the first connector in the device.
-
RJ-45
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Pink
-
Cable shielding:
The protective layer for the cable, typically made of plastic.
-
U/UTP (UTP)
-
Cable standard:
The category of the cable, which is determined by performance characteristics and test requirements.
-
Cat6
-
Cable length:
How long the cable is.
-
7 m
