Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M

Name: Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M SPSMLCSC-OS2-5M
Brand: StarTech
SKU: 11263801
Price: 20.49 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M LC to SC OS2 5m

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 1

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 2

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 3

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 4

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 5

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 6

Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M Photo 7

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

The StarTech.com 5m LC to SC OS2 Single Mode Simplex Fiber Optic Cable features a 9/125µm core diameter, designed for 40G/100G applications. Its bend insensitive design ensures reliable performance even in tight spaces, while low insertion loss guarantees optimal signal quality. Ideal for high-speed data transmission, this LSZH fiber jumper cord is perfect for connecting devices in data centers or network environments.

Available at price 20.49 €: 7 pcs.

Total available for order: 25 pcs.

Warranty: 2 Years

SKU: 11263801

Manufacturer: StarTech

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

06.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.01 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

06.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

Available for private customers at price 23.49 €: 11 pcs.

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

StarTech.com SPSMLCSC-OS2-5M LC to SC OS2 5m is a 5 m OS2 single-mode simplex fiber optic patch cable with 9/125µm core diameter, designed for 40G/100G CWDM applications. The cable supports wavelengths from 1260 to 1625 nm, features LC to SC UPC-polished connectors and a bend-insensitive fiber core within a yellow LSZH jacket. It is compatible with simplex patch panels, SFP transceivers and fiber NICs, and is backward compatible with OS1 networks. Each cable is individually tested for insertion loss and shipped with a test report.

Advantages

The OS2 single-mode construction and UPC-polished LC-to-SC endfaces deliver low insertion loss (below 0.3 dB) and improved return loss compared with older polishing methods. Bend-insensitive fiber and a layer of low refractive index material reduce macrobend losses for reliable signal transmission in constrained routing paths. Compliance with ITU-T G.652.D/G.657.A1 and IEC60703-2-50 type B1.3/B6.a1 standards ensures consistent optical performance. The LSZH flame-retardant jacket reduces smoke and toxic gases in case of fire, making the cable suitable for installations with ventilation or safety restrictions.

Suitable for

Connecting LC to SC ports in data centers and network racks
Linking SFP/SFP+/SFP28 or CWDM transceivers supporting 40G/100G
Simplex patch panel connections and fiber NIC links
Installations requiring LSZH-rated cabling (trains, aircraft, enclosed spaces)

Key specifications

Length: 5 m
Fiber type: OS2 single-mode, 9/125 µm
Connectors: LC (UPC) to SC (UPC)
Wavelength range (CWDM): 1260–1625 nm
Insertion loss: < 0.3 dB (typical)
Jacket: LSZH, colour: yellow
Standards: ITU-T G.652.D / G.657.A1, IEC60703-2-50 B1.3/B6.a1

How to use

Inspect connectors and cable for physical damage before installation. Route the cable through cable management paths avoiding sharp bends and stresses; maintain bend radii recommended for bend-insensitive single-mode fiber. Insert the LC and SC connectors into the corresponding ports on patch panels, transceivers or network interface cards until they click into place. Verify link status on connected devices and, if required, confirm optical loss using the provided test report or a power meter and light source.

Usage recommendations

Store and handle the cable in its original packaging until installation to prevent contamination of UPC endfaces. Clean connector endfaces with an appropriate fiber cleaning tool prior to mating and avoid repeated mating cycles that can increase insertion loss.

Specifications

Cable length:: 5 m
Connector 1:: LC
Connector 2:: SC
Product colour:: Yellow

All features

Data transfer rate:: 100 Gbit/s
Insertion loss:: 0.3 dB
Fiber mode structure:: Single-mode
Core diameter:: 9 µm
Cladding diameter:: 125 µm
Bending radius:: 10 mm
Wavelengths supported:: 1590, 1260, 1280, 1300, 1310, 1383, 1490, 1550, 1600, 1625
Attenuation (max):: 0.35 dB/km
Fibre optic type:: OS2
Return loss:: 55 dB
Connector polish type:: UPC

Features

Cable length:: 5 m
Connector 1:: LC
Connector 2:: SC
Product colour:: Yellow
Jacket material:: Polypropylene, Low smoke zero halogen (LSZH)
Connector 1 gender:: Male
Connector 2 gender:: Male
Cable shape:: Round

Other features

Cable diameter:: 2 mm

Packaging data

Package depth:: 200 mm
Package height:: 2 mm
Package width:: 220 mm

Logistics data

Master (outer) case height:: 280 mm
Master (outer) case width:: 380 mm
Master (outer) case length:: 380 mm
Products per master (outer) case:: 350 pc(s)

Packaging content

Quantity per pack:: 1 pc(s)

Hide Show all

Instructions

mmo_122247876_1724327293_7074_74.pdf

Description

Instructions

mmo_122247876_1724327293_7074_74.pdf

Machine translation. Load original

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Warehouse	Stock	Delivery to the store	Store Price
WH354	11	08.07.2026	23.49 €

Available only for legal entities
Warehouse	Stock	Delivery to the store	Store Price
EU9	7	01.07.2026 Best delivery	20.49 €
WH109	7	15.07.2026	23.49 €

23.49 €

Stock: 11

Delivery Date: 08.07.2026

Warehouse: WH354

Available only for legal entities

20.49 €

Stock: 7

Delivery Date: 01.07.2026 Best delivery

Warehouse: EU9

23.49 €

Stock: 7

Delivery Date: 15.07.2026

Warehouse: WH109

Customer reviews

Show all reviews

Customer questions

FAQ

How much does the Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M cost, and is it available for purchase?

The price is 20.49 € (valid at the time of publication and already includes all taxes). The item is available for order — 25 pcs. are in stock, and you can place your purchase right now with delivery across Latvia and Europe or choose pickup at the Riga collection point. We offer favorable purchase terms, including the option to split the payment into convenient monthly installments. Availability and price are updated in real time, so we recommend placing your order in advance.

If I order this product today, when will I receive my order?

If you place your order today, delivery will be as fast and convenient as possible. You will be able to pick up your order on 01.07.2026 at the Riga pickup point or choose delivery across Latvia and Europe. We carefully inspect every purchase and pack it securely for safe transportation.

What payment options are available?

AiO.lv offers several payment methods: Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay. All transactions are 100% secure and encrypted.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All StarTech products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized StarTech service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: cable length, connector 1, connector 2, product colour, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.

Where can I download the instructions for Fiber Optic Cable StarTech.com SPSMLCSC-OS2-5M?

You can download the instructions in PDF format from the “Instructions” section on the product description page. The file contains complete information about installation, setup, and usage.
