Short description

The Tenda TEG1005M is an unmanaged L2 switch with 5 Gigabit Ethernet ports. It supports a switching capacity of 10 Gbit/s and has a MAC address table with 2000 entries. Ideal for small networks, it adheres to IEEE networking standards and is wall mountable.

Available at price 14.99 €: 1 pcs.

Total available for order: 9 pcs.

Warranty: 2 Years

SKU: 11212170

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

01.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

06.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.24 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

06.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Tenda TEG1005M is an unmanaged L2 switch with five Gigabit Ethernet ports designed for small wired networks. It provides full-duplex transmission up to 2000 Mbps per port and a total switching capacity of 10 Gbit/s, supports a MAC address table of 2000 entries, and conforms to IEEE networking standards. The metal housing and wall-mount design make it suitable for tidy installations and stable operation in surveillance and general networking scenarios.

Advantages

The switch offers full Gigabit ports for uninterrupted high-bandwidth connections, IGMP snooping to optimize multicast traffic for smoother IPTV and video streaming, and auto MDI/MDIX on each port for plug-and-play connectivity without manual configuration. Its stainless-steel grounding screw and metal body improve durability and heat dissipation, while wall-mount holes allow neat cable routing and space-saving installation.

Suitable for

Small office or home wired networks
HD IP surveillance systems and NVR connections
IPTV and multimedia streaming environments requiring multicast optimization
Edge network segments where unmanaged, low-maintenance switches are needed

Key specifications

Model: Tenda TEG1005M (Unmanaged L2)
Ports: 5 × Gigabit Ethernet (10/100/1000) RJ-45
Switching capacity: 10 Gbit/s
MAC address table: 2000 entries
Auto MDI/MDIX on all ports
Networking standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x
Product colour: Black
Weight: 0.17 kg
Power: DC input

How to use

Mount the switch on a wall using the two mounting holes if desired, or place it on a stable surface. Connect each device using standard RJ-45 cables to any of the five Gigabit ports; MDI/MDIX auto-senses cable type so no crossover cable or manual port configuration is required. Provide DC power to the switch and confirm link/activity LEDs to verify connections. For multicast services such as IPTV, ensure connected endpoints are configured to receive multicast streams; the switch will use IGMP snooping to limit multicast traffic to relevant ports.

Usage recommendations

Install the switch in a well-ventilated location to maximize heat dissipation and secure the grounding screw if installing in environments where grounding improves safety. Use quality Cat5e or Cat6 cables for reliable Gigabit performance, and avoid overloading the local network beyond the switch’s unmanaged capabilities.

Specifications

Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Weight:: 0.17 kg
Basic switching RJ-45 Ethernet ports quantity:: 5
10G support:: No
Switch type:: Unmanaged
Networking standards:: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Product colour:: Black

All features

Ports & interfaces

Installed SFP+ modules quantity:: 0
Installed SFP modules quantity:: 0
Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 5

Management features

Switch layer:: L2
Switch type:: Unmanaged

Performance

Compatible operating systems:: Windows 8 32/64 bit , Windows 7 32/64 bit , Windows xp 32/64 bit , Linux , MAC OS

Power

Power source:: DC
AC input frequency:: 50/60
AC input voltage:: 100 - 240
Power consumption (max):: 2.5 W

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Storage temperature (T-T):: -40 - 70
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 5 - 90

Certificates

Certification:: CE , FCC , RoHS

Weight & dimensions

Weight:: 0.17 kg
Height:: 23 mm
Width:: 100 mm
Depth:: 64 mm

Data transmission

MAC address table:: 2000 entries
Switching capacity:: 10 Gbit/s
Jumbo frames support:: Yes
Jumbo frames:: 15000

Packaging data

Package weight:: 270 g
Package depth:: 81 mm
Package height:: 84 mm
Package width:: 102 mm

Network

Networking standards:: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support:: No

Design

LED indicators:: Power, Activity, Link
Wall mountable:: Yes
Product colour:: Black
Housing material:: Metal
