Unmanaged switch TP‑LINK LS105P 5x10/100, 4xPoE

Name: Unmanaged switch TP‑LINK LS105P, 5x LS105LP
Brand: TP-LINK
SKU: 10801415
Price: 17.99 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Unmanaged switch TP‑LINK LS105P, 5x Fast Ethernet (10/100) ports, 4x PoE ports, 1 Gbit/s switching capacity, fanless, black

Unmanaged switch TP‑LINK LS105P 5x10/100, 4xPoE Photo 1

Unmanaged switch TP‑LINK LS105P 5x10/100, 4xPoE Photo 2

Unmanaged switch TP‑LINK LS105P 5x10/100, 4xPoE Photo 3

Unmanaged switch TP‑LINK LS105P 5x10/100, 4xPoE Photo 4

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

TP‑LINK LS105P is an unmanaged 5‑port Fast Ethernet switch with 4 Power over Ethernet (PoE) ports delivering up to 15.4 W per PoE port. The fanless, compact device (100×98×25 mm) supports IEEE 802.3x flow control, auto‑MDI/MDI‑X and auto‑negotiation, store‑and‑forward switching, a 2,000‑entry MAC table and 1 Gbit/s switching capacity. Designed for small offices or home networks to connect and power IP phones, cameras or access points. Includes power supply and wall‑mount option; operates at 0–40 °C.

Available at price 17.99 €: 4 pcs.

Total available for order: 77 pcs.

Warranty: 2 Years

SKU: 10801415

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

15.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

15.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

18.06.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.79 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

18.06.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The 4-port 10/100 Mbps PoE switch provides 41 W total PoE budget and four 802.3af-compliant PoE ports that deliver up to 15.4 W each, enabling power and network connectivity for fixed devices such as IP cameras, wireless access points, and IP phones over a single Ethernet cable. The switch supports an extended PoE transmission mode that increases reach up to 250 m for deployments requiring longer cable runs. Its fanless design and metal enclosure offer quiet, durable operation suitable for desktop placement or wall mounting.

Advantages

The switch is plug-and-play with no configuration required, allowing quick installation. PoE Auto Recovery automatically reboots unresponsive PoE-powered devices to restore connectivity. Silent, fanless operation reduces noise and power consumption. The robust metal housing and flexible mounting options support use in different environments.

Key specifications

Ports: Four 10/100 Mbps Ethernet ports with 802.3af PoE
Total PoE budget: 41 W
Per-port PoE output: Up to 15.4 W
Extended PoE range: Up to 250 m in Extend Mode
Operation: Plug and play, fanless design
Mounting: Desktop or wall-mountable metal enclosure

How to use

Connect the switch to a power source and plug Ethernet cables from the switch ports to your PoE devices such as IP cameras or access points. If devices are located beyond standard Ethernet range, enable Extend Mode to increase PoE transmission distance up to 250 m. The switch requires no additional configuration; PoE ports will detect and power compatible devices automatically. If a PoE device becomes unresponsive, PoE Auto Recovery will attempt an automatic reboot to restore service.

Recommendations

For optimal performance, ensure the combined power draw of connected devices does not exceed the 41 W PoE budget. Use quality Ethernet cabling and follow recommended installation distances for non-extended mode to maintain network reliability.

Specifications

Switch type:: Unmanaged
Basic switching RJ-45 Ethernet ports type:: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity:: 5
10G support:: No
Product colour:: Black
Networking standards:: IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

All features

Management features

Quality of Service (QoS) support:: Yes
Switch type:: Unmanaged

Ports & interfaces

Installed SFP+ modules quantity:: 0
Installed SFP modules quantity:: 0
Basic switching RJ-45 Ethernet ports type:: Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity:: 5

Packaging content

User guide:: Yes

Power

Power source:: DC/PoE
Input current:: 0.81
AC input frequency:: 50
AC input voltage:: 220
DC input voltage:: 53.5
Power consumption (max):: 46.45 W
Power supply included:: Yes

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Storage temperature (T-T):: -40 - 70
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 5 - 90
Heat dissipation:: 157.93 BTU/h

Packaging data

Package type:: Box

Certificates

Certification:: CE, FCC, RoHS

Weight & dimensions

Height:: 25 mm
Width:: 100 mm
Depth:: 98 mm

Data transmission

MAC address table:: 2000 entries
Switching capacity:: 1 Gbit/s
Jumbo frames support:: Yes
Store-and-forward:: Yes
Forwarding rate:: 0.744 Mpps

Design

LED indicators:: Y
Wall mountable:: Yes
Product colour:: Black
Number of fans:: 0 fan(s)

Power over Ethernet (PoE)

Power over Ethernet (PoE):: Yes
Power over Ethernet (PoE) ports quantity:: 4
Power over Ethernet (PoE) power per port:: 15.4 W

Network

Networking standards:: IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Flow control support:: Yes
Auto MDI/MDI-X:: Yes
10G support:: No
Copper ethernet cabling technology:: 10BASE-T, 100BASE-TX
Cable types supported:: Cat3, Cat4, Cat5, Cat5e
Auto-negotiation:: Yes

Performance

Fanless:: Yes
