UN straight white drainage channel 110 mm with chrome grate K10PH

The UN straight white drainage channel 110 mm with chrome grate K10PH is a linear runoff collector designed for surface water management. The unit pairs a white channel body with a chrome-finish grate and connects to a 110 mm drainage pipe, enabling efficient redirection of water into existing sewer or storm systems. It is intended for use where discreet, low-profile surface drainage is required, providing a practical solution for patios, driveways, terraces and building perimeters.

Advantages

The product combines a lightweight, corrosion-resistant channel body in white with a durable chrome-finish grate that resists weathering and allows smooth water entry. Its straight design facilitates straightforward alignment and installation along linear runs. Compatibility with a 110 mm pipe connection simplifies integration with standard drainage networks and reduces the need for special adapters. The chrome grate offers an aesthetic finish that complements residential and light commercial exteriors while maintaining functional performance.

Suitable for

• Surface drainage for patios and terraces
• Driveway runoff collection
• Perimeter drainage around buildings
• Integration with 110 mm sewer or stormwater systems

Key specifications

• Connection diameter: compatible with 110 mm drainage pipe
• Channel body color: white
• Grate finish: chrome
• Design: straight linear channel for inline runs
• Application: surface water collection for residential and light commercial areas

How to use

Position the straight drainage channel along the intended runoff path, ensuring correct slope toward the 110 mm outlet for gravity flow. Prepare a stable bedding (concrete or compacted aggregate) to support the channel body, set the unit in place, and ensure alignment with adjacent channels or end pieces as needed. Connect the outlet to the 110 mm drainage pipe using standard couplings or solvent-weld techniques appropriate for the pipe material. Fasten the chrome grate onto the channel body and verify that the grate sits flush for unobstructed surface flow.

Usage recommendations

Maintain the grate by removing debris regularly to prevent blockages and inspect the connection to the 110 mm pipe periodically for sediment buildup. Use suitable bedding and backfill materials to avoid channel movement under load, and select grate placement to minimize exposure to concentrated heavy vehicle loads unless the product specification confirms load class suitability.
